ROTOR DISC » RN1126V
Specification
Type
Vented
Disc Thickness (Max)
24
Num. of holes
4
Height
44
Centering Diameter
61
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
280
Drum Ø:
136
Structure Material
G3000
Cross Reference
BENDIX EUR
562103B
OEM
7701201320
OEM
7701205086
RENAULT
40 20 605 40R
RENAULT
40 20 680 53R
RENAULT
40 20 695 18R
RENAULT
77 00 426 389
RENAULT
77 01 205 230
RENAULT
77 01 205 842
RENAULT
77 01 206 118
RENAULT
77 01 207 829
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
06.13~09.19 | 1200 | H5F 403 | J5_ | RN1126V | PN0551 | DN1322H | FN43551 | |
06.13~09.19 | 1200 | H5F 403 | J5_ R451 LHD CHL | RN1126V | PN0551 | DN1322H | FN43551 | |
06.13~09.19 | 1500 | K9K 608 | J5AL | RN1126V | PN0551 | DN1322H | FN43551 | |
06.13~09.19 | 1500 | K9K 628 | J5AJ | RN1126V | PN0551 | DN1322H | FN43551 |
05.05~03.09 | 1200 | D4F 7# | CR# 3DR | RN1126V | PN2800 | RN1173DN1611DN1611H | FN1255PN0019W | |
04.09~03.13 | 1600 | K4M 862 | CR10 3DR | RN1126V | PN2800PN9805 | DN1611HRN1173DN1611 | PN0019WFN1255 | |
05.05~03.13 | 2000 | M4R 70# | BR# 5DR | RN1126V | PN0249W | PN0270 | ||
05.05~03.13 | 2000 | M4R 70# | CR# 3DR | RN1126V | PN0249W | PN0270 |
07.01~01.08 | 1200 | D4F 7# | FC / KC | RN1037VRN1126V | PN0151PN0350 | RN1875DN1606 | FN0597PN0194FN1230 | |
06.97~07.01 | 1200 | D7F 7# | FC / KC | RN1126VRN1037V | PN0151PN0350 | DN1606RN1875 | PN0194FN1230FN0597 | |
06.97~01.08 | 1400 | E7J | FC / KC | RN1126VRN1037V | PN0350PN0151 | RN1875DN1606 | FN1230FN0597PN0194 | |
06.97~01.08 | 1400 | K7J 70_ | FC / KC | RN1037VRN1126V | PN0151PN0350 | DN1606RN1875 | PN0194FN1230FN0597 | |
06.97~01.08 | 1500 | K9K 7# | FC / KC | RN1037VRN1126V | PN0151PN0350 | RN1875DN1606 | FN1230FN0597PN0194 | |
04.03~07.08 | 1600 | K4M 753 | FC1N | RN1037VRN1126V | PN0350PN0151 | RN1875 | PN0194FN0597 | |
07.01~01.08 | 1600 | K4M7# | FC / KC | RN1126VRN1037V | PN0350PN0151 | RN1875DN1606 | FN1230FN0597PN0194 | |
06.97~07.01 | 1600 | K7M 74# | FC / KC | RN1037VRN1126V | PN0151 | RN1875DN1606 | FN1230FN0597PN0194 | |
06.97~01.08 | 1900 | F8Q 6 | FC / KC | RN1037VRN1126V | PN0151PN0350 | DN1606RN1875 | PN0194FN1230FN0597 | |
06.97~01.08 | 1900 | F9Q | FC / KC | RN1126VRN1037V | PN0151PN0350 | DN1606RN1875 | FN1230PN0194FN0597 | |
04.03~01.08 | 1900 | F9Q790 | KCAV VAN EU LHD | RN1126VRN1037V | PN0151PN0350 | DN1606RN1875 | FN0597PN0194FN1230 |
11.97~03.01 | 1600 | K4M 72# | LB/ESTATE | RN1126V | PN0249W | DN1610 | FN0602PN0114 | |
11.93~03.01 | 1800 | F3P# | LB/ESTATE | RN1126V | PN0249W | DN1610 | PN0282FN0602PN0114 | |
04.98~03.01 | 1800 | F4P 760 | LB/ESTATE | RN1126V | PN0249W | DN1610 | FN0602PN0114 | |
10.97~03.01 | 1900 | F9Q 71# | LB/ESTATE | RN1126V | PN0249W | DN1610 | FN0602PN0114 | |
11.93~03.01 | 2000 | F3R 7# | LB/ESTATE | RN1126V | PN0249W | DN1610 | FN0602 | |
09.99~03.01 | 2000 | F4R 7# | LB/ESTATE | RN1126V | PN0249W | DN1610 | PN0114FN0602 | |
11.93~03.01 | 2200 | G8T 7# | LB/ESTATE | RN1126V | PN0249W | DN1610 | PN0114PN0282FN0602 | |
03.97~03.01 | 3000 | L7X 70# | LB/ESTATE | RN1126V | PN0249W | DN1610 | PN0282FN0602PN0114 | |
11.93~03.01 | 3000 | Z7X 76# | LB/ESTATE | RN1126V | PN0249W | DN1610 | PN0114PN0282FN0602 |
03.99~09.02 | 1400 | K4J 750 | KA0W EST LHD | RN1126VRN1037V | PN0284WPN0249W | FN0600PN0270 | ||
03.95~09.03 | 1600 | K4M 70# | BA0# | RN1126VRN1037VRN1000 | PN0284WPN0249W | FN0550 | ||
05.00~08.02 | 1800 | F4P 722 | BA1M | RN1126V | PN0249W | PN0019W | ||
03.95~09.03 | 2000 | F7R 71# | BA0# | RN1126V | PN0249W | PN0270 |
03.95~09.03 | 1400 | K4J 750 | LA0# | RN1126V | PN0249WPN0284W | PN0270FN0550 | ||
03.95~09.03 | 1600 | K4M 70# | LA0# | RN1002VRN1126V | PN0249WPN0284W | PN0270FN0550 | ||
03.95~09.03 | 1900 | F9Q 73# | LA0# | RN1126V | PN0284WPN0249W | FN0550 |
03.95~09.03 | 1400 | K4J 750 | DA0# | RN1126V | PN0284WPN0249W | FN0550PN0270 | ||
03.99~09.03 | 1600 | K4M 700 | EA0_ | RN1126V | PN0249W | PN0270FN0550 | ||
01.06~09.09 | 1600 | K4M 812 | EM1R | RN1126V | PN0204 | RN1173 | PN0019W | |
09.03~09.09 | 2000 | F4R 770 | EM__ | RN1126V | PN0350 | RN1173 | PN0019W | |
03.99~09.03 | 2000 | F5R 740 | EA0# | RN1126V | PN0249W | PN0270 |
09.02~09.09 | 1400 | K4J 73# | #M | RN1126VRN1187V | PN0362 | RN1173 | PN0019W | |
09.02~10.06 | 1500 | K9K 722 | BM0F HB | RN1126V | PN0350 | RN1173 | PN0019W | |
09.02~09.09 | 1500 | K9K 724 | BM1F | RN1126V | PN0204 | RN1173 | PN0019W | |
02.06~09.09 | 1500 | K9K 732 | K84 ESTATE LHD | RN1126V | PN0204 | RN1880H | PN0019W | |
09.02~09.09 | 1600 | K4M | BM__ | RN1126V | PN0350PN0204 | RN1173 | PN0019W | |
09.02~09.09 | 1600 | K4M | KM__ | RN1126V | PN0350PN0204 | RN1880H | PN0019W | |
09.02~09.09 | 1600 | K4M | LM__ | RN1126V | PN0204PN0350 | RN1173 | PN0019W | |
09.02~10.06 | 1600 | K4M 760 | LM1B | RN1126V | PN0350 | RN1173 | PN0019W | |
09.02~09.09 | 1600 | K4M 761 | CM0C | RN1126V | PN0350 | RN1173 | PN0019W | |
09.02~09.09 | 1900 | F9Q 800 | #M | RN1126V | PN0350 | PN0019W | ||
09.02~09.09 | 2000 | F4R 77# | #M | RN1126V | PN0350PN0362 | PN0521PN0019W | ||
09.02~09.09 | 2000 | F4R 770 | CM05 | RN1126V | PN0350 | RN1173 | PN0019W | |
09.02~09.09 | 2000 | F4R 771 | EM1N | RN1126V | PN0204PN0350 | RN1173 | PN0019W | |
01.02~12.10 | 2000 | F4R 771 | LM0U | RN1126V | PN0350 | RN1173 | PN0019W | |
01.02~12.10 | 2000 | F4R 771 | LM1N | RN1126V | PN0350PN0204 | RN1173 | PN0019W | |
01.02~12.10 | 2000 | F4R 774 | BM1U | RN1126V | PN0204 | RN1173 | PN0019W |
03.99~09.03 | 1400 | K4J 750 | JA0W | RN1126V | PN0249W | PN0019W | ||
09.99~09.03 | 1400 | K4J714 | JA# / FA# | RN1126V | PN0249W | FN0547PN0019W | ||
09.99~01.04 | 1600 | K4M 701 | JA04 | RN1126V | PN0249W | PN0019W | ||
03.99~09.03 | 1600 | K4M7# | JA# / FA# | RN1126V | PN0249W | PN0019WFN0547 | ||
07.00~09.03 | 1800 | F4P 72# | JA# / FA# | RN1126V | PN0249W | FN0547PN0019W | ||
03.99~09.03 | 1900 | F8Q7# | JA# / FA# | RN1126V | PN0249W | PN0019WFN0547 | ||
03.99~09.03 | 1900 | F9Q 73# | JA# / FA# | RN1126V | PN0249W | FN0547PN0019W | ||
09.99~08.03 | 1900 | F9Q 732 | JA05 | RN1126V | PN0249W | PN0019W | ||
11.00~09.03 | 1900 | F9Q74 | JA# / FA# | RN1126V | PN0249W | PN0019WFN0547 | ||
11.00~09.03 | 1900 | F9Q74 | JA# / FA# | RN1126V | PN0249WPN0204 | FN0547PN0019W | ||
03.99~09.03 | 2000 | F4R 74# | JA# / FA# | RN1126V | PN0249W | FN0547PN0019W | ||
09.99~08.03 | 2000 | F4R 741 | JA1B | RN1126V | PN0249W | PN0019W |
04.03~11.08 | 1400 | K4J7# | JM# | RN1879VRN1126V | PN0204PN0350 | RN1880H | PN0019W | |
06.05~07.09 | 1500 | K9K7# | JM# | RN1879VRN1126V | PN0204PN0350 | RN1880H | PN0019W | |
04.03~06.05 | 1500 | K9K72# | JM# | RN1879VRN1126V | PN0350 | RN1880H | PN0019W | |
01.03~01.09 | 1600 | K4M 761 | JM0C | RN1879VRN1126V | PN0350 | RN1880H | PN0019W | |
04.03~07.09 | 1600 | K4M 8# | JM# | RN1126VRN1879V | PN0350PN0204 | RN1880H | PN0019W | |
04.03~07.09 | 1600 | K4M76# | JM# | RN1879VRN1126V | PN0204PN0350 | RN1880H | PN0019W | |
04.03~07.09 | 1900 | F9Q 8# | JM# | RN1879VRN1126V | PN0350PN0204 | RN1880H | PN0019W | |
03.04~07.09 | 2000 | F4R 776 | JM# | RN1879VRN1126V | PN0204PN0350 | RN1880H | PN0019W | |
10.05~07.09 | 2000 | M9R 7# | JM# | RN1879VRN1126V | PN0204 | RN1880H | PN0019W |
