DRUM BRAKE » DN1131

DN1131

Specification

Outter Ø
216
Num. of holes
4
Centering Diameter
62
Height
51.5
Pitch Circle Ø
100
Drum Ø
180
Hole Ø
12.8
Structure Material
G3000

Cross Reference

SUZUKI
43511-81P00
SUZUKI
43511-81P00-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Ignis

02.16~02.24 1200 K12C FF21S JPN RN2720V PN9443 DN1131 FN9806
01.16~02.20 1200 K12C FH11S LHD RN2392V PN9813 DN1131 FN9806
01.16~02.20 1200 K12C FH11S RHD RN2392V PN9813 DN1131 FN9806
09.19~ 1200 K12D ATK412 RN2392VRN2720V PN9813PN9443 DN1131 FN9806
01.16~02.20 1200 K12M FH81S RHD RN2720V PN9443 DN1131 FN9806
09.19~ 1200 K12M FH81S RHD RN2720V PN9443 DN1131 FN9806

SUZUKI   »   Solio

08.15~11.20 1200 K12C MA26S RN2720V PN9443 DN1131 FN9806
08.15~11.20 1200 K12C hybrid MA36S RN2720V PN9443 DN1131 FN9806

SUZUKI   »   Swift V

01.20~ 1200 K12C A2L412-4 LHD ZC53S RN2461V PN9812 DN1131 FN9806
01.17~ 1200 K12M A2L412 LHD RN2461V PN9812 DN1131 FN9806
09.20~ 1200 K12M ZC63S RN2461V PN9812 DN1131 FN9806
01.17~ 1200 K12MS ZC63S RN2461VRN2393V PN9812PN5562 DN1131RN2394 FN9806PN9808
