ROTOR DISC » RN11003
Specification
Type
Solid
Outter Ø
262
Num. of holes
4
Disc Thickness (Max)
10
Height
44
Centering Diameter
62.6
Pitch Circle Ø
100
Front/Rear
Rear
Drum Ø:
156
Disc Thickness (Min)
8.4
Structure Material
G3000
Variation
Cross Reference
HYUNDAI
58411-0U300
HYUNDAI / KIA
58411C8000
KIA
58411-0U300
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.10~10.14 | 1400 | G4FA | PSB11 SDN LHD | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 10.10~10.14 | 1400 | G4FA | PSB11 SDN RHD | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.11~05.14 | 1400 | G4LC | CT41 RHD | RN11002V | PN0537 | RN11003 | PN0538 | |
| 11.10~12.14 | 1600 | D4FB | PSB11 SDN DOM | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.11~12.14 | 1600 | D4FB | SB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 HB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 HB LHD PR | RN11002V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 SDN | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 |
| 01.14~01.19 | 1400 | G4LC | CT41 RHD | RN11002V | PN0537 | DN1456RN11003 | PN0538FN0609 | |
| 01.14~01.20 | 1400 | G4LC | CT41 SDN LHD | RN11002V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 01.14~01.19 | 1400 | G4LC | CT51 | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.14~01.19 | 1400 | G4LC | CU41 SDN RHD | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.14~02.20 | 1600 | D4FB | PSB15 LHD | RN11002V | PN0537 | DN1456RN11003 | PN0538FN0609 | |
| 05.14~11.17 | 1600 | G4FC | PSB15 SDN | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 |
| 01.18~ | 1400 | G4LC | PH618 LHD VTN | RN11002VRN1956V | PN0537 | RN11003DN1509 | PN0538FN0609 | |
| 01.18~ | 1400 | G4LC | PH618 RHD | RN1956V | PN0537 | RN11003DN1509 | PN0538FN0609 | |
| 12.17~ | 1600 | G4FG | PH618 LHD | RN1956V | PN0537 | RN11003 | PN0538 |
| 03.21~ | 1000 | G3LF | PSW21 | RN2072V | PN0603 | RN11003 | PN0538 | |
| 03.21~ | 1200 | G4LF | PSW21 | RN2072V | PN0603 | RN11003 | PN0538 | |
| 03.21~ | 1400 | G4LC | PSW21 | RN2072V | PN0603 | RN11003 | PN0538 |
| 01.16~06.18 | 1000 | G3LC | HB EU | RN2072VRN1956V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 06.18~03.20 | 1000 | G3LC | PC818 5DR HB EL | RN2072VRN1956V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 08.20~ | 1000 | G3LE | BC3 | RN11003 | ||||
| 11.14~06.18 | 1100 | D3FA | HB EU | RN1956VRN2072V | PN0537 | DN1456RN11003 | PN0538FN0609 | |
| 11.14~06.18 | 1200 | G4LA | HB EU | RN2072VRN1956V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 11.14~06.18 | 1200 | G4LA | PC715 RHD | RN11002VRN2072V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 08.20~ | 1200 | G4LF | BC3 | RN11003 | ||||
| 11.14~06.18 | 1400 | D4FC | HB EU | RN2072VRN1956V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 08.20~ | 1400 | G4LC | BC3 | RN11003 | ||||
| 06.18~03.20 | 1400 | G4LC | GB | RN2072VRN1956V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 11.14~06.18 | 1400 | G4LC | HB EU | RN2072VRN1956V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 11.14~06.18 | 1400 | G4LC | PC715 RHD | RN11002V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 06.18~08.20 | 1400 | G4LC | PC718 LHD | RN11002V | PN0603PN0537 | RN11003 | PN0538 | |
| 08.20~ | 1600 | G4FP | BC3 | RN11003 |
| 02.20~ | 1400 | G4LC | H520 | RN1956V | PN0537 | DN1509RN11003 | FN0609PN0538 | |
| 02.20~ | 1600 | G4FG | H520 | RN1956V | PN0537 | RN11003DN1509 | FN0609PN0538 |
| 03.11~05.14 | 1400 | G4FA | SBR11 RUS | RN11002V | PN0537 | DN1509RN11003 | PN0538FN0609 | |
| 11.10~05.14 | 1600 | G4FC | SBR11 RUS | RN11002V | PN0537 | RN11003 | PN0538 |
| 01.17~08.20 | 1400 | G4LC | H517 | RN1956V | PN0537 | DN1509RN11003 | PN0538FN0609 | |
| 01.17~08.20 | 1600 | G4FG | H517 | RN1956V | PN0537 | DN1509RN11003 | FN0609PN0538 |
| 09.11~ | 1100 | D3FA | UB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.11~ | 1400 | D4FC | UB | RN11002V | PN0537 | RN11003 | FN0609PN0538 | |
| 07.11~02.15 | 1400 | G4FA | DXR12 RUS | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.11~01.14 | 1400 | G4FA | PIH12 3DR HB | RN11002V | PN0537 | DN1456RN11003 | PN0538FN0609 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 5DR HB LHD | RN11002V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 5DR HB RHD | RN11002V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 07.11~02.15 | 1600 | G4FC | DXR12 | RN11002V | PN0537 | RN11003 | PN0538 | |
| 03.11~03.15 | 1600 | G4FD | PIH12 4DR SDN LHD | RN11002V | PN0537 | RN11003 | PN0538 |
| 09.14~ | 1400 | D4FC | DN51 | RN2072V | PN0537 | RN11003 | PN0538 | |
| 11.14~06.17 | 1400 | G4FA | PIH15 5DR HB | RN11002V | PN0537 | DN1456RN11003 | PN0538FN0609 | |
| 01.15~06.17 | 1600 | G4FC | DXR15 HB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.15~06.17 | 1600 | G4FC | DXR15 SDN RU | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.15~06.17 | 1600 | G4FD | PIH15 SDN | RN11002V | PN0537 | RN11003 | PN0538 |
| 11.16~01.20 | 1400 | G4LC | PH817 HB LHD | RN1956V | PN0537 | RN11003 | PN0538 | |
| 11.16~08.20 | 1400 | G4LC | PH817 HB RHD | RN1956V | PN0537 | RN11003DN1509 | PN0538FN0609 |
