ROTOR DISC » RN11002V
Specification
Type
Vented
Outter Ø
256
Num. of holes
4
Disc Thickness (Max)
22
Height
43.8
Centering Diameter
62
Pitch Circle Ø
100
Front/Rear
Front
Drum Ø:
125
Disc Thickness (Min)
20
Structure Material
G3000
Variation
Cross Reference
HYUNDAI
51712-0U000
HYUNDAI
51712-1R000
HYUNDAI
51712-1S300
HYUNDAI
51712-1W200
HYUNDAI
51712-1W250
HYUNDAI
51712-R1300
HYUNDAI / KIA
51712-0U100
HYUNDAI / KIA
51712-0U500
HYUNDAI / KIA
51712-K8100
KIA
51712-0U000
KIA
51712-1W250
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.10~10.14 | 1400 | G4FA | PSB11 SDN LHD | RN11002V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 10.10~10.14 | 1400 | G4FA | PSB11 SDN RHD | RN11002V | PN0537 | RN11003 | PN0538 | |
| 11.11~09.14 | 1400 | G4FA | SB HB | RN11002V | PN0537 | DN1456 | FN0609 | |
| 09.11~05.14 | 1400 | G4LC | CT41 LHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 09.11~05.14 | 1400 | G4LC | CT41 RHD | RN11002V | PN0537 | RN11003 | PN0538 | |
| 11.10~12.14 | 1600 | D4FB | PSB11 SDN DOM | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.11~12.14 | 1600 | D4FB | SB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 HB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 HB LHD PR | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 09.11~05.14 | 1600 | G4FC | PSB11 SDN | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 09.11~05.14 | 1600 | G4FD | SB | RN11002V | PN0537 | DN1456 | FN0609 |
| 01.14~01.19 | 1400 | G4LC | CT41 RHD | RN11002V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 01.14~01.20 | 1400 | G4LC | CT41 SDN LHD | RN11002V | PN0537 | RN11003DN1456 | PN0538FN0609 | |
| 01.14~01.19 | 1400 | G4LC | CT51 | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.14~01.19 | 1400 | G4LC | CU41 SDN RHD | RN11002V | PN0537 | RN11003 | PN0538 | |
| 09.14~02.20 | 1600 | D4FB | PSB15 LHD | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 05.14~11.17 | 1600 | G4FC | PSB15 SDN | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 |
| 12.14~08.20 | 1200 | G4LA | BL51 5DR RHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 11.14~09.17 | 1200 | G4LA | PC715 RHD | RN11002VRN2072V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 11.14~06.18 | 1400 | D4FC | PC715 RHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 11.14~06.18 | 1400 | G4LC | PC715 RHD | RN11002V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 06.18~08.20 | 1400 | G4LC | PC718 LHD | RN11002V | PN0537PN0603 | RN11003 | PN0538 | |
| 06.18~08.20 | 1400 | G4LC | PC718 RHD | RN11002V | PN0603PN0537 | DN1456 | FN0609 |
| 03.11~05.14 | 1400 | G4FA | SBR11 RUS | RN11002V | PN0537 | RN11003DN1509 | PN0538FN0609 | |
| 11.10~05.14 | 1600 | G4FC | SBR11 RUS | RN11002V | PN0537 | RN11003 | PN0538 |
| 05.14~12.16 | 1400 | G4FA | SBR14 RUS | RN11002V | PN0537 | DN1509 | FN0609 | |
| 05.14~12.16 | 1600 | G4FC | SBR14 RUS | RN11002V | PN0537 | RN11003DN1509 | FN0609 |
| 09.11~ | 1100 | D3FA | UB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 03.11~05.15 | 1200 | G4LA | DN511 5DR HB RHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 03.11~05.15 | 1200 | G4LA | PIH12 4DR SDN RHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 09.11~ | 1400 | D4FC | UB | RN11002V | PN0537 | RN11003 | FN0609PN0538 | |
| 07.11~02.15 | 1400 | G4FA | DXR12 RUS | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.11~01.14 | 1400 | G4FA | PIH12 3DR HB | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 4DR SDN LHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 4DR SDN RHD | RN11002V | PN0537 | DN1456 | FN0609PN0538 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 5DR HB LHD | RN11002V | PN0537 | DN1456RN11003 | PN0538FN0609 | |
| 03.11~05.15 | 1400 | G4FA | PIH12 5DR HB RHD | RN11002V | PN0537 | RN11003DN1456 | FN0609PN0538 | |
| 07.11~02.15 | 1600 | G4FC | DXR12 | RN11002V | PN0537 | RN11003 | PN0538 | |
| 03.11~03.15 | 1600 | G4FD | PIH12 4DR SDN LHD | RN11002V | PN0537 | RN11003 | PN0538 |
| 01.15~04.17 | 1200 | G4LA | DN511 5DR HB RHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 07.15~03.17 | 1200 | G4LA | PIH15 5DR HB LHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 07.15~03.17 | 1200 | G4LA | PIH15 SDN LHD | RN11002V | PN0537 | DN1456 | FN0609 | |
| 01.15~06.17 | 1400 | G4FA | DXR15 RUS | RN11002V | PN0537 | DN1509 | FN0609 | |
| 11.14~06.17 | 1400 | G4FA | PIH15 5DR HB | RN11002V | PN0537 | DN1456RN11003 | FN0609PN0538 | |
| 01.15~06.17 | 1400 | G4FA | PIH15 SDN | RN11002V | PN0537 | DN1456 | FN0609 | |
| 01.15~06.17 | 1600 | G4FC | DXR15 HB | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.15~06.17 | 1600 | G4FC | DXR15 SDN RU | RN11002V | PN0537 | RN11003 | PN0538 | |
| 01.15~06.17 | 1600 | G4FD | PIH15 SDN | RN11002V | PN0537 | RN11003 | PN0538 |
