ROTOR DISC » RN1355
Specification
Type
Solid
Disc Thickness (Max)
12
Num. of holes
5
Height
58.5
Centering Diameter
64
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
282
Disc Thickness (Min)
10
Structure Material
G3000
Drum Ø:
158.5
Cross Reference
BENDIX
562284B
HONDA
42510-S7A-J00
HONDA
42510-S7A-J50
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.04~12.06 | 1700 | D17A | BE2 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 01.04~06.12 | 2000 | K20A | BE3 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 07.04~08.09 | 2000 | K20A | BE4 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 12.06~08.09 | 2400 | K24A | BE8 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 06.04~08.06 | 1700 | D17A2 | BE1 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
| 08.06~11.09 | 1800 | R18A1 | BE1 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
| 01.05~11.09 | 2000 | K20A9 | BE3 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
| 01.05~11.09 | 2200 | N22A1 | BE5 | RN1218V | PN8465 | RN1355 | PN8807 | FN0570 |
| 10.00~07.06 | 1700 | D17A# | RN1 GR | RN1218VRN1468V | PN8264PN8465 | RN1355DN1380 | FN5524PN8397 | FN0570 |
| 10.00~07.06 | 1700 | D17A# | RN1 JPN | RN1468VRN1218V | PN8264PN8465 | RN1355DN1380 | PN8397FN5524 | FN0570 |
| 10.00~07.06 | 2000 | K20A | RN3 JPN | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 10.00~07.06 | 2000 | K20A | RN4 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 10.00~07.06 | 2000 | K20A1 | RN3 LHD | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 10.00~09.03 | 2000 | K20A1 | RN3 RHD | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 09.03~07.06 | 2000 | K20A1 | RN3 RHD | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
| 12.03~07.06 | 2000 | K20B | RN5 | RN1218V | PN8465 | RN1355 | PN8397 | FN0570 |
