ROTOR DISC » RN1349V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
49
Centering Diameter
69.2
Front/Rear
Front
Outter Ø
321
Drum Ø:
143
Pitch Circle Ø
114.3
Disc Thickness (Min)
26
Structure Material
G3000
Cross Reference
HYUNDAI
51712-2B700
HYUNDAI
51712-2P700
HYUNDAI
51712-2W700
HYUNDAI / KIA
51712-3J000
HYUNDAI / KIA
51712-3J010
KIA
51712-2P700
KIA
51712-2W700
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.18~ | 2400 | G4KE | KRUSPS118 | RN2279VRN1349V | PN11003PN0662 | RN2280VRN2281V | PN0754PN6123 | |
| 08.15~01.19 | 2400 | G4KE | PDM15 LHD | RN1349V | PN0789 | RN1712 | PN0415 | FN0691 |
| 09.06~07.09 | 2200 | D4EB | CM | RN1349V | PN0446 | RN2002 | PN0415PN0447 | FN0664 |
| 09.06~01.10 | 2700 | G6EA | CM GL | RN2287VRN1349V | PN0446 | RN2002 | PN0447 | FN11005 |
| 09.06~01.10 | 2700 | G6EA | CM LHD RU | RN1349V | PN0446 | RN2002 | PN0447 | FN11005 |
| 12.05~01.10 | 2700 | G6EA | CM SG RHD | RN2287VRN1349V | PN0446 | RN2002 | PN0447 | FN11005 |
| 08.09~08.12 | 2200 | D4HB | SH81 | RN1349V | PN0446 | RN1712 | PN0415 | FN0664FN0697 |
| 08.09~09.12 | 2400 | G4KE | PCM10 LHD | RN1349V | PN0446 | RN1712 | PN0415 | FN0664FN0697 |
| 08.09~09.12 | 2400 | G4KE | SH81 | RN1349V | PN0446 | RN1712 | PN0415 | FN0664 |
| 08.09~09.12 | 3500 | G6DC | SH81 LHD | RN1349V | PN0446 | RN1712 | PN0415 | FN0697 |
| 05.12~07.15 | 2400 | G4KE | DM LHD | RN1652VRN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 2400 | G4KJ | PDM12 | RN1349V | PN0446 | RN1712 | PN0415 | FN0697FN0691 |
| 10.06~01.15 | 3000 | D6EA | EN07 | RN1349V | PN0456 | PN0457 | FN0715 | |
| 10.06~01.15 | 3800 | G6DA | EN07 | RN1349V | PN0456 | PN0457 | FN0715 | |
| 10.06~01.15 | 3800 | G6DA | EN07 GEN | RN1349V | PN0456 | PN0457 | FN0715 |
| 05.09~07.12 | 2200 | D4HB | KEURPXM09 | RN1349V | PN0446 | RN1712 | PN0415 | FN0664FN0697 |
| 05.09~07.12 | 2200 | D4HB | KGENPXM09 | RN1349V | PN0446 | RN1712 | PN0415 | FN0664FN0697 |
| 05.09~07.12 | 2400 | G4KE | XM09 | RN1349V | PN0446 | RN1712 | PN0415 | FN0664 |
| 05.09~07.12 | 3500 | G6DC | XM09 | RN1349V | PN0446 | RN1712 | PN0415 | FN0697 |
| 07.12~08.14 | 2000 | D4HA | XM12 | RN1652VRN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
| 07.12~08.14 | 2200 | D4HB | XM12 LHD | RN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
| 07.12~08.14 | 2200 | D4HB | XM12 RHD | RN1652VRN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
| 07.12~08.14 | 2400 | G4KE | XM12 | RN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
| 07.12~08.14 | 2400 | G4KJ | XM | RN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
