NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2287V

ROTOR DISC » RN2287V

Specification

Type

Vented

Outter Ø

298

Num. of holes

5

Hole Ø:

12.6

Disc Thickness (Max)

28

Disc Thickness (Min)

26.4

Height

49.2

Centering Diameter

69

Pitch Circle Ø

114.3

Drum Ø:

141.8

Front/Rear

Front

Structure Material

G3000

Cross Reference

HYUNDAI

51712-2B000

HYUNDAI / KIA

51712-2P000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Santa Fe 06

10.05~09.06	2200	D4EB	PA06 LHD	RN2287V	PN0446	RN2002	PN0447	FN11005
09.06~07.09	2200	D4EB	PCM 06 LHD	RN2287V	PN0446	RN2002	PN0447	FN11005
09.06~01.10	2700	G6EA	CM GL	RN2287V RN1349V	PN0446	RN2002	PN0447	FN11005
12.05~01.10	2700	G6EA	CM SG RHD	RN2287V RN1349V	PN0446	RN2002	PN0447	FN11005
01.06~08.09	2700	G6EA	CM US	RN2287V	PN0446	RN2002	PN0447	FN11005
04.06~07.09	3300	G6DB	CMA06	RN2287V	PN0446	RN2002	PN0447	FN11005
04.06~07.09	3300	G6DB	PCM06	RN2287V	PN0446	RN2002	PN0447	FN11005
