NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1266V

ROTOR DISC » RN1266V

Specification

Type

Vented

Disc Thickness (Max)

28

Num. of holes

6

Height

45.5

Centering Diameter

84

Front/Rear

Front

Pitch Circle Ø

127

Outter Ø

285

Drum Ø:

152

Disc Thickness (Min)

26

Structure Material

G3000

Cross Reference

OEM

4251226160

TOYOTA

43512-26140

TOYOTA

43512-26160

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Granvia / Grand Hiace

08.95~04.98	2700	3RZ-FE	RCH11W	RN1266V	PN1516 PN1237	RN1605V DN1115	FN2330 PN1363	FN0567
08.96~05.02	3000	1KZ-TE	KCH10W	RN1266V	PN1516 PN1237	RN1605V	FN2330 PN1363	FN0567
05.97~05.02	3400	5VZ-FE	VCH10W	RN1266V	PN1516 PN1237	RN1605V	PN1363
07.99~05.02	3400	5VZ-FE	VCH22K	RN1266V	PN1516 PN1237	DN1115	FN2330

TOYOTA » Hiace

08.03~01.05	2000	1TR-FE	TRH122K	RN1266V	PN1516 PN1237		FN2330
08.03~01.05	2000	1TR-FE	TRH124B	RN1266V	PN1237 PN1516		FN2330
03.97~08.01	2400	2L	LXH22	RN1266V RN1304V	PN1237		FN2330
08.95~08.01	2400	2L	LXH28	RN1304V RN1266V	PN1237		FN2330
08.95~08.01	2400	2L-T	LXH12L	RN1266V	PN1516 PN1237	DN1115	FN2330
08.95~08.01	2400	2L-T	LXH22	RN1266V RN1304V	PN1237		FN2330
08.95~08.01	2400	2L-T	LXH28	RN1266V RN1304V	PN1237		FN2330
08.95~08.01	2400	2RZ-E	LXH12R	RN1266V	PN1237 PN1516	DN1115	FN2330
08.95~08.01	2400	2RZ-E	LXH22	RN1304V RN1266V	PN1237		FN2330
08.95~08.01	2400	2RZ-E	RCH12L	RN1266V	PN1516 PN1237	DN1115	FN2330
08.01~11.11	2500	2KD-FTV	KLH12R	RN1266V	PN1237 PN1516	DN1115	FN2330
08.01~11.11	2500	2KD-FTV	KLH22R	RN1266V	PN1516 PN1237	DN1115	FN2330
04.98~08.04	2700	3RZ-FE	RCH13L	RN1266V	PN1237	DN1115	FN2330
08.89~08.98	2800	3L	LH113K	RN1266V RN1475V	PN1227	DN1209	FN2330 FN2317

TOYOTA » Hiace Commuter

08.98~08.04	3000	5L-E	LH172R	RN1266V	PN1516 PN1237		FN2330
08.89~02.06	3000	5L-E	LH172V	RN1266V	PN1516 PN1237		FN2330

TOYOTA » Hiace Regius

08.89~08.03	2000	1RZ-#	RZH112K	RN1266V RN1475V	PN1227 PN1516 PN1237		FN2252 FN2335 FN2330
08.89~07.03	2000	1RZ-#	RZH124B	RN1475V RN1478V RN1266V	PN1227 PN1237 PN1516		FN2330 FN2317
08.89~08.03	2000	1RZ-E	RZH102V	RN1475V RN1266V	PN1227 PN1237 PN1516	DN1209	FN2330 FN2317
08.89~07.03	2000	1RZ-E	RZH112V	RN1266V RN1475V	PN1227 PN1237 PN1516	DN1209	FN2335 FN2317 FN2330
12.00~08.04	2000	1RZ-E	RZH182K	RN1266V	PN1516 PN1237		FN2330
08.03~08.04	2000	1TR-FE	TRH102V	RN1266V	PN1237 PN1516		FN2330
08.03~08.04	2000	1TR-FE	TRH112K	RN1266V	PN1516 PN1237		FN2330
08.03~08.04	2000	1TR-FE	TRH112V	RN1266V	PN1237 PN1516		FN2330
12.00~08.04	2000	2RZ-E	RZH183K	RN1266V	PN1516 PN1237		FN2330
08.98~08.03	2400	2RZ-E	RZH125B	RN1266V	PN1237 PN1516		FN2330
08.89~07.99	2800	3L	LH113V	RN1475V RN1266V	PN1516 PN1237 PN1227	DN1209	FN2330 FN2317
08.86~08.98	2800	3L	LH123V	RN1266V RN1475V	PN1227 PN1516 PN1237	DN1209	FN2317 FN2330
08.98~08.04	3000	5L	LH162V	RN1266V	PN1237 PN1516		FN2330
08.98~08.04	3000	5L-E	LH182K	RN1266V	PN1516 PN1237		FN2330
08.98~08.04	3000	5L-E	LH184B	RN1266V	PN1237 PN1516		FN2330

TOYOTA » Hiace Regius Touring

06.97~05.02	2000	3RZ-FE	RCH42V	RN1266V	PN1516 PN1237	DN1115	FN2330
04.97~05.02	2700	3RZ-FE	RCH41W	RN1266V	PN1516 PN1237	RN1605V	PN1363	FN0567
04.97~07.99	3000	1KZ-TE	KCH40G	RN1266V	PN1516 PN1237	RN1605V	PN1363	FN0567
04.97~05.02	3000	1KZ-TE	KCH40W	RN1266V	PN1237 PN1516	RN1605V	PN1363	FN0567
04.97~08.04	3000	5L-E	LXH43V	RN1266V	PN1237 PN1516	DN1115	FN2330
