ROTOR DISC » RN1478V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
45.5
Centering Diameter
84
Front/Rear
Front
Pitch Circle Ø
110
Outter Ø
285
Disc Thickness (Min)
26
Drum Ø:
150
Structure Material
G3000
Cross Reference
BENDIX
562118B
TOYOTA
43512-26120
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.89~01.05 | 2400 | 2RZ-E | RZH113L | RN1478VRN1475V | PN1227PN1237PN1516 | DN1209 | FN2330FN2317 | |
| 08.89~02.06 | 2400 | 2RZ-E | RZH113R | RN1478VRN1475V | PN1227PN1237 | FN2330 | ||
| 08.93~08.99 | 2800 | 3L | LH103V | RN1478VRN1475V | PN1237PN1227 | FN2330 | ||
| 08.95~08.04 | 3000 | 1KZ-TE | KZH132V | RN1478V | PN1516PN1237 | FN2330 |
| 08.89~08.04 | 2400 | 2L | LH102L | RN1475VRN1478V | PN1227PN1237FN2251PN1516 | DN1209 | ||
| 08.89~02.06 | 2400 | 2L | LH104L | RN1478VRN1475V | PN1237FN2251PN1516PN1227 | DN1209 | FN2317FN2330 | |
| 08.89~02.06 | 2400 | 2RZ | RZH103R | RN1478VRN1475V | PN1237PN1227 | DN1209 | FN2317FN2330 | |
| 08.89~01.00 | 2800 | 3L | LH115B | RN1478VRN1475V | PN1227 | FN2330FN2317 | ||
| 08.89~01.00 | 2800 | 3L | LH115R | RN1478VRN1475V | PN1227PN1237 | DN1209 | FN2317FN2330 | |
| 08.89~02.06 | 3000 | 5L-E | LH174R | RN1475VRN1478V | PN1516PN1227PN1237 | FN2330 |
| 08.89~07.03 | 2000 | 1RZ-# | RZH124B | RN1266VRN1475VRN1478V | PN1237PN1516PN1227 | FN2330FN2317 | ||
| 08.89~08.95 | 2000 | 1RZ-E | RZH100G | RN1475VRN1478V | PN1227PN1516PN1237 | DN1209 | FN2317FN2330 | |
| 08.89~02.08 | 2400 | 2RZ-E | RZH101G | RN1475VRN1478V | PN1516PN1227PN1237 | DN1209 | FN2317FN2330 | |
| 08.95~08.02 | 2400 | 2RZ-E | RZH111G | RN1478V | PN1237PN1516 | FN2330 | ||
| 08.95~07.99 | 2400 | 2RZ-E | RZH133V | RN1478V | PN1516PN1237 | FN2330 | ||
| 08.89~08.98 | 2800 | 3L | LH125B | RN1475VRN1478V | PN1227 | DN1209 | FN2330FN2317 | |
| 08.93~08.04 | 3000 | 1KZ-TE | KZH100G | RN1478V | PN1237PN1516 | DN1209 | FN2330 | |
| 08.93~08.04 | 3000 | 1KZ-TE | KZH110G | RN1478V | PN1237PN1516 | DN1209 | FN2330 | |
| 08.95~08.04 | 3000 | 1KZ-TE | KZH110G | RN1478V | PN1516PN1237 | DN1209 | FN2330 | |
| 08.93~08.04 | 3000 | 1KZ-TE | KZH120G | RN1304VRN1478V | PN1516PN1237 | DN1209 | FN2330FN2305 | |
| 08.98~08.04 | 3000 | 5L-E | LH162R | RN1475VRN1478V | PN1516PN1237PN1227 | FN2330FN2335 |
| 08.89~02.06 | 2000 | 1RZ-E | RZH102 | RN1475VRN1478V | PN1237PN1227 | DN1209 | FN2330FN2317 | |
| 08.89~02.06 | 2400 | 2L | LH112R | RN1478VRN1475V | PN1237PN1516PN1227FN2251 | FN2330 | ||
| 08.89~02.06 | 2400 | 2L | LH114R | RN1475VRN1478V | PN1237FN2251PN1227PN1516 | DN1209 | ||
| 08.89~08.05 | 2400 | 2RZ-E | RZH115L | RN1478VRN1475V | PN1237PN1516PN1227 | DN1209 | FN2330 | |
| 08.89~09.05 | 2800 | 3L | LH113R | RN1478VRN1475V | PN1237FN2251PN1516PN1227 | FN2330 |
