ROTOR DISC » RN2647V

RN2647V

Specification

Type
Vented
Outter Ø
319
Num. of holes
6
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
67.7
Centering Diameter
108
Pitch Circle Ø
139.7
Drum Ø:
172
Front/Rear
Front
Structure Material
G3000

Cross Reference

JAC
3501050P3010
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JAC   »   T6

01.18~ 2000 4DB2-1D1 HFC1037DKV RN2647V PN1482 PN9818PN0797

JAC   »   T8 Pro

10.20~ 2000 HFC4DB2-2E T8 Pro RN2647V PN1482 RN2648V PN6055

JAC   »   T9

05.23~ 2000 N20TG T9 RN2647V PN1482 RN2648V PN6055
