ROTOR DISC » RN2846V

RN2846V

Specification

Type
Vented
Outter Ø
312
Num. of holes
6
Hole Ø:
14.5
Disc Thickness (Max)
18
Height
68.3
Centering Diameter
108
Pitch Circle Ø
139.7
Drum Ø:
210
Front/Rear
Rear
Structure Material
G3000
Disc Thickness (Min)
16

Cross Reference

JAC
3504050P3031N
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JAC   »   T6

01.18~ 2000 4DB2-1D1 HFC1037DKV RN2647V PN1482PN6003 RN2759VRN2846V PN0797PN9818
