ROTOR DISC » RN2759V

RN2759V

Specification

Type
Vented
Outter Ø
324
Num. of holes
6
Hole Ø:
14
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
89.6
Centering Diameter
108
Pitch Circle Ø
139.7
Drum Ø:
210
Front/Rear
Rear
Structure Material
G3000

Cross Reference

JAC
3504050P3031
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JAC   »   T6

01.18~07.21 2000 4DB2-1D1 HFC1037DKV RN2647V PN1482PN6003 RN2759V PN0797PN9818
