ROTOR DISC » RN1986

Specification

Type
Solid
Outter Ø
215
Num. of holes
4
Disc Thickness (Max)
12
Height
44.2
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
121
Disc Thickness (Min)
10
Structure Material
G3000

Cross Reference

MAZDA
1A04-33-251
MAZDA
1A04-33-251A
NISSAN
0206-4A0A1
NISSAN
40206-4A00F
NISSAN
40206-4A0A1
NISSAN
40206-4A0A2
NISSAN
40206-4A0A3
NISSAN
40207-4A0A2
SUZUKI
55311-67H00
SUZUKI
55311-67H10
SUZUKI
55311-67H11
SUZUKI
55311-76G00
SUZUKI
55311-76G10
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.04~01.05 660 K6A HB24S RN1985RN1986 PN9426PN9523 FN9967
04.02~12.04 660 K6A# MG21S RN1986RN1787V PN9523PN9426 FN9967FN9959
10.98~12.00 660 F6A HA12V RN1986 PN9426 FN9959PN8206
04.04~05.05 660 K6A HA24S RN1986RN1985 PN9523PN9426 FN9967
01.99~09.01 660 F6A DA52V RN1986 PN9439 DN1117 FN9962
01.99~09.01 660 F6A# DA52T RN1986 PN9439 FN5524FN9951
12.98~01.05 660 F6A# DB52T RN1986 PN9439 FN9951
12.98~01.05 660 F6A# DB52V RN1986 PN9439 FN9951
04.99~10.01 660 F6A-T DA52W RN1986 PN9439 DN1117 FN9962
08.01~08.03 660 K6A DA62T RN1986 PN9439 FN9951
09.01~09.05 660 K6A DA62V RN1986 PN9439 FN9962
05.02~11.05 660 K6A DA63T RN2013RN1986 PN9523PN9426 FN9966FN5524
09.01~08.05 660 K6A# DA62W RN1986 PN9439 FN9962
03.01~10.09 660 K6A HN22S RN1921VRN1986 PN9426PN9443 FN9967PN8206FN9959
09.98~04.01 660 K6A# HN21S RN1921VRN1986 PN9443PN9426 FN9959
10.98~12.00 660 K6A# MC21S RN1986 PN9426 FN9959

Exemption from liability: the catalog data is advisory and can be used for reference only
