ROTOR DISC » RN1787V

Specification

Type
Vented
Outter Ø
231
Num. of holes
4
Disc Thickness (Max)
17
Height
49.2
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
125
Structure Material
G3000
Disc Thickness (Min)
15
Front/Rear
Front

Cross Reference

MARUTI
55311M66R00
MARUTI
55311M69P00
MARUTI
55311M75F00
MARUTI
55311M75J20
MARUTI
55311M75J30
MARUTI
55311M75J40
MARUTI
55311M75J50
NISSAN
40206-4A00A
NISSAN
40206-4A00C
NISSAN
40206-4A0A0
SUZUKI
55311-75F11
SUZUKI
55311-M75J30
SUZUKI
5531175F00
SUZUKI
5531175F10
SUZUKI
55311M66R00
SUZUKI
55311M66R00-000
SUZUKI
55311M75F00
SUZUKI
55311M75J30-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.02~ 1100 DA468Q HFJ71 RN1787V PN0725
01.02~ 1100 DA468Q HFJ71 RN1787V PN0725
01.01~12.10 1000 F10D FB21S RN1787V PN9443 FN9959
11.14~ 1300 D13A RN1787V PN9529 FN9807
09.15~ 1300 D13A RN1787V PN9529 FN9807
12.16~ 1200 K12M MIG RN1787V PN9815 FN9809
04.09~09.12 1200 K12M RN1787V PN9529
09.12~ 1200 K12M RN1787V PN9529
04.09~09.12 1300 D13A RN1787V PN9529
09.12~ 1300 D13A RN1787V PN9529
04.10~12.11 1200 K12M RN1787V PN9529
08.11~02.18 1200 K12M ZF62S RN1787V PN9529 FN9807
04.07~08.11 1300 D13A RN1787V PN9529
08.11~ 1300 D13A RN1787V PN9529 FN9807
04.05~03.10 1300 G13B RN1787V PN9529
04.10~03.12 1200 K12M RN1787V PN9529
02.12~ 1200 K12M RN1787V PN9529 FN9807
03.08~03.12 1300 D13A RN1787V PN9529
02.12~ 1300 D13A RN1787V PN9529 FN9807
03.08~01.10 1300 G13B RN1787V PN9529
01.06~12.10 1100 F10D RN1787V PN9426
01.00~12.03 1100 FC RN1787V PN9426
01.03~12.06 1100 FC RN1787V PN9426
04.02~02.06 660 K6A# MG21S RN1986RN1787V PN9523PN9426 FN9959FN9967
02.06~02.11 660 K6A# MG22S RN1787VRN1985 PN9523 FN9967
10.98~08.04 1000 K10A HA62S RN1787V PN9426 FN9959FN9967
06.02~04.04 1100 F10D FF21 RN1787V
06.05~12.09 1100 F10D RF410 RN1787V PN9443 FN9959
01.02~02.09 660 K6A# HE21S RN1985RN1787V PN9426PN9523 FN9959FN9967
09.01~12.10 1300 M13A ME34S RN1787V PN9406 FN9959
09.14~ 1400 K14B AVB414 RN2245VRN1787V PN9529 FN9991FN9807
08.18~ 1500 K15B AVB415-2 LHD RN1787V FN9807
05.17~ 1200 K12M RN1787V PN9529 FN9807
10.16~ 1200 K12C FG81S RHD RN1787V PN9815 FN9809
01.05~12.10 660 K6A# MF22S RN1787VRN1985 PN9523 FN9967
09.19~ 1000 K10BN FL41S RN1787V PN9443
05.22~ 1000 K10CN FL61S RN1787V
09.07~05.15 1200 K12MN XB72S RHD RN1787V PN9529 FN2386
08.11~01.14 1200 K12M ZC62S HB LHD RN1787V PN9529 FN9807
08.11~02.18 1200 K12MN AZI412 SDN RN1787V PN9529 FN9807
02.13~02.18 1200 K12MN AZI412 SDN TYPE 2 RHD RN1787V PN9529 FN9807
10.13~05.18 1200 K12MN ZC62S HB LHD RN1787V PN9529 FN9807
08.11~02.18 1200 K12MN ZC62S HB RHD RN1787V PN9529 FN9807
08.11~02.18 1200 K12MN ZC62S HB RHD RN1787V PN9529 FN9807
08.11~01.15 1200 K12MN ZF62S SDN RHD RN1787V PN9529 FN9807
01.15~02.18 1200 K12MN ZF62S SDN RHD RN1787V PN9529 FN9807
11.00~11.02 1000 K10A MA64S RN1787V PN9406 FN9959
12.00~08.05 1300 M13A MA34S RN1787V PN9406 FN9959
02.97~06.99 1000 K10A MB61S RN1787V PN9406 FN9959FN9944
05.99~11.00 1000 K10A MA63S RN1787V PN9406 FN9959
06.97~06.00 1000 K10A SR410 RN1787V PN9406 DN1370 FN9944
02.97~06.00 1200 K12A SR412-2 RN1787V PN9406 DN1370 FN9944

Exemption from liability: the catalog data is advisory and can be used for reference only
