ROTOR DISC » RN1936V

RN1936V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
47.1
Centering Diameter
64
Pitch Circle Ø
114.3
Drum Ø:
153.3
Structure Material
G3000
Front/Rear
Front
Hole Ø:
12.7

Cross Reference

HONDA
45251-TZ3-A00
HONDA
45251-TZ5-A00
HONDA
45251-TZ5-A01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ACURA   »   MDX

06.13~12.20 3500 J35Y4 YD3 RN2219VRN1936V PN0645 RN1937 PN0648PN0646 FN8005
05.13~06.16 3500 J35Y4 YD4 RN2632VRN1936V PN0645 RN1937 PN0646PN0648 FN8005

ACURA   »   TLX

07.14~07.20 2400 K24W7 UB1 RN1936VRN1406V PN28003PN8865 RN1695 PN0648
07.14~07.20 3500 J35Y6 UB2,UB3 RN1406VRN1936V PN28003PN8865 RN1695 PN0648
