NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1937

ROTOR DISC » RN1937

Specification

Type

Solid

Outter Ø

330

Num. of holes

5

Hole Ø:

14,5

Disc Thickness (Max)

11

Disc Thickness (Min)

9

Height

59.2

Centering Diameter

64

Pitch Circle Ø

114.3

Front/Rear

Rear

Structure Material

G3000

Cross Reference

HONDA

42510-TZ5-A00

HONDA

42510-TZ5-A01

HONDA

42510-TZ5-A02

HONDA

42510-TZ5-A03

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

ACURA » MDX

06.13~12.20	3500	J35Y4	YD3	RN2219V RN1936V	PN0645	RN1937	PN0646 PN0648	FN8005
05.13~12.20	3500	J35Y4	YD4	RN1936V RN2219V	PN0645	RN1937	PN0648 PN0646	FN8005
