ROTOR DISC » RN1815V

Specification

Type
Vented
Outter Ø
266.7
Num. of holes
6
Disc Thickness (Max)
22
Height
39.2
Front/Rear
Front
Drum Ø:
166
Disc Thickness (Min)
20
Pitch Circle Ø
124
Centering Diameter
100
Structure Material
G3000

Cross Reference

BENDIX
561401B
BENDIX
561456B
BENDIX
561720B
NISSAN
4020610W00
NISSAN
4020610W01
NISSAN
4020635G01
OEM
4020635G00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.88~01.97 2700 TD27# BMD21 RN1815VRN1028V PN2344PN2105 FN1189FN1171
09.85~04.92 2400 Z24# D21 RN1815V PN2105 DN1289DN1302 FN1189FN1171
09.85~10.87 2500 SD25 D21 RN1815V PN2105 DN1289 FN1171
10.87~02.98 2500 TD25 D21 RN1815VRN1333V PN2105 DN1296DN1302 FN1174FN1189
03.92~12.97 2500 TD25 D21 RN1815V PN0372 FN1189
07.86~12.95 2700 TD27 WD21 RN1815V PN2105 DN1296DN1289 FN1174FN1171
11.85~01.92 2500 SD25 D21 RN1815V
08.86~10.93 2700 TD27 VBYD21 RN1815V PN2105 DN1289DN1296 FN1171FN1174
11.86~05.94 2000 LD20 VUGJNC22 RN1815V PN2105 DN1297 FN1174

Exemption from liability: the catalog data is advisory and can be used for reference only
