DRUM BRAKE » DN1297

Specification

Outter Ø
266
Num. of holes
4
Hole Ø
12.7
Centering Diameter
68.2
Height
63
Pitch Circle Ø
114.3
Drum Ø
230
Structure Material
G3000

Cross Reference

NISSAN
40206-21000
NISSAN
40206-21001
NISSAN
40206-U4800
NISSAN
40206-Y9500
NISSAN
43206-4M700
NISSAN
43206-56L10
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.90~01.99 1600 GA16DS VENW10 RN1814V PN2188 DN1297 FN1170
05.90~08.98 1600 GA16DS VEW10 RN1814VRN1039V PN2176PN2188 RN1817DN1297 PN2224FN1170
01.93~08.98 1800 SR18DE W10 RN1814VRN1039V PN2188PN2176 RN1817DN1297 PN2224FN1170
05.90~01.93 1800 SR18Di W10 RN1814V PN2188 DN1297 FN1170
05.90~08.98 2000 CD20 VSW10 RN1039VRN1814V PN2176PN2188 DN1297RN1817 PN2224FN1170
10.90~08.98 2000 SR20DE# PNW10 RN1039V PN2176PN2309 DN1297RN1817 PN2224FN1170
01.89~03.94 2400 KA24E M11 RN1039V PN2176 DN1325DN1297 FN1170
09.87~09.89 1800 CA18# RNU12 RN1039V PN2176 DN1297 FN1170PN2130
09.91~11.95 1800 SR18DE ENU13 RN1039V PN2176 RN1817DN1297 PN2224FN1198
09.91~11.95 2000 CD20 SNU13 RN1039V PN2176 RN1817DN1297 FN1198PN2224
08.00~12.05 1800 QG18DE QNG10 RN1039V PN2435 DN1297 FN1170
12.88~01.93 1800 CA18i FC33 PN2199 DN1297 FN1170
11.88~06.94 2000 CA20S A31 RN1039V PN2176 DN1297 FN1170
12.88~01.93 2800 RD28 SC33 RN1039V PN2176PN2199 DN1297 PN2200FN1170 FN0698
09.88~01.95 2000 CA20S M11 DN1297
09.88~08.95 2000 CA20S NM11 RN1039V PN2176PN2245 DN1297 FN1170PN2130
09.90~08.95 2400 KA24E HM11 RN1039V PN2176PN2245 DN1297 FN1170
09.90~08.95 2400 KA24E HNM11 PN2245 DN1297 FN1170PN2130
01.92~01.95 2400 KA24E M11 DN1297
07.90~01.98 1600 GA16DE W10 PN2176 DN1297 PN2224FN1170
07.90~01.98 2000 CD20 W10 RN1039V PN2176 RN1040DN1297 PN2224FN1170
07.92~11.01 1600 GA16DE C23M RN1094V PN2213PN2105 DN1297DN1325 FN1225
05.89~08.93 1800 CA18i FR32 PN2199 DN1297 FN1170
10.98~11.04 1500 QG15DE FNB15 RN1039V PN2435 DN1297 FN1170
09.85~04.93 1500 A15S VPJC22 RN1455V PN2105PN2149 DN1297 FN1170
11.88~03.94 2000 LD20 UJC22 PN2149 DN1297 FN1170
09.85~03.94 2000 LD20 VUJC22 PN2149 DN1297 FN1170
09.88~03.94 2000 LD20 VUJNC22 RN1039V PN2176 DN1297 FN1170
09.88~06.91 2000 LD20-T KUJNC22 RN1039V PN2176 DN1297 FN1170
11.86~05.94 2000 LD20 VUGJNC22 RN1815V PN2105 DN1297 FN1174
06.91~01.97 1600 GA16DE KAJC23 RN1814V PN2188PN2245 DN1297DN1325 FN1198FN1193
06.91~08.93 2000 CD20 KVJC23 RN1814V PN2245PN2188 DN1297DN1325 FN1193FN1198
06.91~06.99 2000 CD20 VVJC23 RN1814V PN2188 DN1325DN1297 FN1198FN1193

Exemption from liability: the catalog data is advisory and can be used for reference only
