NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1370

DRUM BRAKE » DN1370

Specification

Outter Ø

208

Num. of holes

4

Centering Diameter

51-51.9

Height

82

Pitch Circle Ø

100

Drum Ø

180

Structure Material

G3000

Hole Ø

12

Cross Reference

SUZUKI

43511-75F01

SUZUKI

43511-75F01-000

SUZUKI

43511-75F02

SUZUKI

43511-75F02-000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUZUKI » Wagon R+

06.97~06.00	1000	K10A	SR410	RN1787V	PN9406	DN1370	FN9944
02.97~06.00	1200	K12A	SR412-2	RN1787V	PN9406	DN1370	FN9944
