BRAKE SHOE » FN9915

Specification

Radius
90
Width
34
Thickness
5.5
Pcs In Set
4

Cross Reference

KASHIYAMA
K9915
SUZUKI
52200-84800
SUZUKI
52200-84801
SUZUKI
52201-84010
SUZUKI
52201-84011
SUZUKI
52201-84012
SUZUKI
5220181010
SUZUKI
5220181011
SUZUKI
5220181020
SUZUKI
52202-81020
SUZUKI
52202-84010
SUZUKI
52202-84011
SUZUKI
52202-84012
SUZUKI
52202-84020
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.86~09.88 550 F5A CA72V RN2129 PN9124FN9915 FN7728
10.84~09.88 550 F5A# CA71V PN9124FN9915 FN7728
09.88~03.90 550 F5B# CL11V PN9183FN9915PN9213 FN9931
01.85~01.88 550 F5A# SS40 FN9915PN9124 FN9907
09.84~07.88 550 F5A CB71S FN9915PN9124 FN7728
01.87~09.89 550 F5A CB72S PN9124FN9915 FN7728
01.85~10.88 550 F5A SS40T PN9124FN9915 FN9907

Exemption from liability: the catalog data is advisory and can be used for reference only
