ROTOR DISC » RN2129

Specification

Type
Solid
Outter Ø
215
Num. of holes
4
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
33
Centering Diameter
86
Pitch Circle Ø
102
Drum Ø:
106
Front/Rear
Front
Structure Material
G3000

Cross Reference

BENDIX
561425B
DAEWOO
91122289
DAEWOO
96052404
GM
91122289
GM
96052404
MARUTI
55511M82000
MARUTI
55511M82010
OEM
30005701
OEM
55311A60B11000
OEM
55511-82010
OEM
5551160B11
OEM
5551182
OEM
55511M82001
SUZUKI
55311-60B11
SUZUKI
5531160B11A00
SUZUKI
55311A60B11
SUZUKI
55511-78400
SUZUKI
55511-78401
SUZUKI
55511-82000
SUZUKI
55511-82001
SUZUKI
55511-M82000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.97~12.00 800 F8D RN2129 PN9124 FN7728
01.00~12.14 800 F8D RN2129 PN9124 FN7728
01.05~ 800 F8B RN2129 PN9124 FN9910
01.93~01.03 1000 G10B RN2129 PN9124
06.04~03.06 1000 G10B RN2129 PN9124
08.99~01.03 1000 G10B RN2129 PN9124
07.86~09.88 550 F5A CA72V RN2129 PN9124FN9915 FN7728
03.85~05.89 550 F5A DB71T RN2129 FN9910PN9124 FN9919
03.85~05.89 550 F5A DB71V RN2129 FN9910PN9124 FN9919
05.89~03.90 550 F5B DB41T RN2129 PN9408 FN9919
03.90~09.91 660 F6A DB51T RN2129 PN9408 FN9919
03.90~05.95 660 F6A DD51# RN2129 PN9408FN9932 FN9943FN9951FN9952FN9932FN9919
01.90~09.91 660 F6A# DA51V RN2129 PN9408 FN9919FN9923
03.90~09.91 660 F6A# DB51V RN2129 PN9408 FN9923
09.91~12.98 660 F6A# DF51V RN2129 PN9408 FN9943
08.92~01.99 1000 F10A SK410 RN2129 PN9124FN9910PN9408 DN1851 FN9923FN9943
01.08~ 1000 F10A SK410 VTN RN2129 PN9124 FN9910FN9923

Exemption from liability: the catalog data is advisory and can be used for reference only
