DRUM BRAKE » DN1371

Specification

Outter Ø
262
Num. of holes
5
Hole Ø
14.3
Centering Diameter
62
Height
59.2
Pitch Circle Ø
114.3
Drum Ø
220
Structure Material
G3000

Cross Reference

FIAT
71742701
FIAT
71768381
SUZUKI
43511-79J00
SUZUKI
43511-79J00-000
SUZUKI
43511-79J01
SUZUKI
43511-79J01-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.06~ 1600 189 RN1320V PN9803 DN1371 FN0634
06.06~ 1600 M16A 189 RN1320V PN9803 DN1371 FN0634
03.06~09.09 1900 D19AA 189 RN1320V PN9803 DN1371RN1755 PN8398FN0634
06.06~12.11 1600 M16A RW416 MAGYAR RN1320V PN9803 DN1371RN1755 PN8398FN0634

Exemption from liability: the catalog data is advisory and can be used for reference only
