ROTOR DISC » RN1731V

RN1731V

Specification

Type
Vented
Num. of holes
5
Pitch Circle Ø
120
Front/Rear
Rear
Outter Ø
350
Disc Thickness (Max)
25
Height
49
Centering Diameter
79
Disc Thickness (Min)
23
Drum Ø:
173
Structure Material
G3000
Hole Ø:
14.5

Variation

RN1731DSET[NiBK]

Cross Reference

LAND ROVER
LR033302
LAND ROVER
LR099036
LAND ROVER
LR161898
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LAND ROVER   »   Discovery IV

09.09~02.13 5000 508PN/AJ133 LR4 PN0488 RN1731V PN0485

LAND ROVER   »   Discovery V

09.16~ 2000 204DTA L462 RN2343V PN47004 RN1731V PN47001
09.17~ 2000 AJ200P/PT204 L462 RN2343V PN47004 RN1731V PN47001
09.16~ 3000 306PS L462 RN2343V PN47004 RN1731V PN47001
09.16~ 3000 30DDTX L462 RN1760VRN2151V PN0488PN0941 RN1731VRN2339V PN47001

LAND ROVER   »   Range Rover IV

09.17~04.22 3000 306DT L405 RN2343V PN47004 RN1731V PN47001
09.12~09.17 3000 306DT L405 RHD RN1760V PN0488W RN1731V PN47001
05.13~09.19 3000 306PS L405 RN1760V PN0488W RN1731V PN47001

LAND ROVER   »   Range Rover Sport

01.13~05.17 3000 306PS LWA2VE RN1760V PN0488W RN1731V PN47001
