ROTOR DISC » RN2343V

Specification

Type
Vented
Outter Ø
363
Num. of holes
5
Hole Ø:
14.5
Disc Thickness (Max)
33
Disc Thickness (Min)
31
Height
62
Centering Diameter
79
Pitch Circle Ø
120
Drum Ø:
225
Front/Rear
Front
Structure Material
G3000

Cross Reference

LAND ROVER
LR098967
LAND ROVER
LR161893
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.16~ 2000 204DTA L462 RN2343V PN47004 RN1731V PN47001
09.17~ 2000 AJ200P/PT204 L462 RN2343V PN47004 RN1731V PN47001
09.16~ 3000 306PS L462 RN2343V PN47004 RN1731V PN47001
09.17~04.22 3000 306DT L405 RN2343V PN47004 RN1731V PN47001

Exemption from liability: the catalog data is advisory and can be used for reference only
