ROTOR DISC » RN1665V
Specification
Type
Vented
Outter Ø
310
Num. of holes
5
Disc Thickness (Max)
18
Height
67
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
186/190
Disc Thickness (Min)
16.4
Structure Material
G3000
Front/Rear
Rear
Variation
Cross Reference
LEXUS
42431-30290
TOYOTA
42431-30290
TOYOTA
42431-30310
TOYOTA
42431-30330
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 12.11~10.15 | 2500 | 4GR-FSE | GRL11 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 12.11~10.15 | 2500 | 4GR-FSE | GRL11R | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 01.05~12.11 | 3000 | 3GR-FE | GRS190 | RN1244VRRN1244VSETRN1244VL | PN1547PN1479 | RN1665V | PN1494 | FN0659 |
| 01.05~12.11 | 3000 | 3GR-FSE | GRS190 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 01.05~07.06 | 3000 | 3GR-FSE | GRS195 | RN1536V | PN1479 | RN1665V | PN1494 | FN0659 |
| 03.12~07.20 | 3500 | 22GRFXE | GWL10 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1846 | FN0699 |
| 10.15~07.20 | 3500 | 2GR-FKS | GRL12 | PN1547 | RN1665V | PN1846 | FN0699 | |
| 10.15~07.20 | 3500 | 2GR-FKS | GRL16 | RN1498VLRN1498VR | PN1547 | RN1665V | PN1846 | FN0699 |
| 12.11~10.15 | 3500 | 2GR-FSE | GRL10L | PN1547 | RN1665V | PN1846 | FN0699 | |
| 08.05~12.11 | 3500 | 2GR-FSE | GRS191 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1494 | FN0659 |
| 08.05~12.11 | 3500 | 2GR-FSE | GRS196 | RN1498VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 08.05~07.16 | 3500 | 2GR-FSE | GRS196L | RN1498VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 01.05~09.08 | 4300 | 3UZ-FE | UZS190 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 01.05~09.08 | 4300 | 3UZ-FE | UZS190R | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1494 | FN0659 |
| 02.06~12.11 | 3500 | 2GR-FSE | GWS191 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 03.12~07.20 | 3500 | 2GR-FXE | GWL10 | RN1244VSETRN1244VRRN1244VL | PN1547 | RN1665V | PN1846 | FN0699 |
| 04.09~07.15 | 3000 | 3GR-FE | GSE22 | RN1244VLRN1244VRRN1258VRN1244VSET | PN1829PN1547 | RN1665V | PN1494PN1846 | FN0659 |
| 08.05~04.13 | 3500 | 2GR-FSE | GSE21 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 04.13~ | 3500 | 2GR-FSE | GSE31 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1846 | FN0699 |
| 04.13~09.20 | 3500 | 2GR-FSE | GSE31L | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1846 | FN0699 |
| 08.15~09.20 | 3500 | 2GR-FSE | GSE37L | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1846 | FN0699 |
| 02.08~12.12 | 3500 | 2GR-FSE | GRS204 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 12.12~04.18 | 3500 | 2GR-FSE | GRS214 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | FN0659 | |
| 02.08~02.13 | 3500 | 2GR-FSE | GWS204 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 02.08~12.12 | 2500 | 4GR-FSE | GRS200 | RN1536V | PN1479 | RN1665V | PN1494 | FN0659 |
| 02.08~12.12 | 2500 | 4GR-FSE | GRS201 | RN1536V | PN1479 | RN1665V | PN1494 | FN0659 |
| 09.05~02.08 | 3500 | 2GR-FSE | GRS184 | PN1547 | RN1665V | PN1494 | FN0659 | |
| 02.08~12.12 | 3500 | 2GR-FSE | GRS204 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 12.03~02.08 | 2500 | 4GR-FSE | GRS180 | RN1536VRN1258VRN1536VSET | PN1550PN1479 | RN1665V | PN1494 | |
| 12.03~02.08 | 2500 | 4GR-FSE | GRS181 | RN1536VRN1258V | PN1479PN1550 | RN1438RN1665V | PN1494 | FN0659 |
| 11.04~02.08 | 3000 | 3GR-FSE | GRS182 | RN1536VRN1258V | PN1550PN1479 | RN1438RN1665V | PN1494 | FN0659 |
| 07.04~03.09 | 4300 | 3UZ-FE | UZS186 | RN1536V | PN1479 | RN1665V | PN1494 | FN0659 |
| 03.09~09.13 | 4600 | 1UR-FSE | URS206 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1494 | FN0659 |
