ROTOR DISC » RN1258V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
49.3
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
296
Drum Ø:
149
Disc Thickness (Min)
26
Structure Material
G3000
Variation
Cross Reference
LEXUS
4351230310
TOYOTA
43512-0P010
TOYOTA
43512-30310
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.05~04.13 | 2500 | 4GR-FSE | GSE20 | RN1258V | PN1829 | RN1438 | PN1494 | FN0659 |
| 08.05~08.10 | 2500 | 4GR-FSE | GSE25 | RN1258VRN1536VRN1536VSET | PN1479PN1829 | RN1438 | PN1494 | FN0659 |
| 04.13~08.15 | 2500 | 4GR-FSE | GSE30L | RN1258V | PN1829PN1550 | RN1438 | PN1846 | FN0659 |
| 04.13~08.15 | 2500 | 4GR-FSE | GSE30R | RN1258V | PN1550 | RN1438 | PN1846 | FN0659 |
| 04.13~08.15 | 2500 | 4GR-FSE | GSE35 | RN1258VRN1150V | PN1829PN1324PN1550 | RN1438 | PN1421PN1846 | FN0659 |
| 08.03~04.13 | 2500 | 4GR-FSE | GSE20L | RN1536VRN1258V | PN1479PN1829 | RN1665VRN1438 | PN1494 | FN0659 |
| 04.06~04.13 | 3000 | 3GR-FE | GSE22 | RN1258V | PN1547PN1829 | RN1438 | PN1494 | FN0659 |
| 04.09~07.15 | 3000 | 3GR-FE | GSE22 | RN1244VLRN1244VRRN1258VRN1244VSET | PN1829PN1547 | RN1665V | PN1494PN1846 | FN0659 |
| 04.13~ | 2500 | 2AR-FSE | AVE30 | RN1258V | PN1550PN1829 | RN1438 | PN1846 | FN0659 |
| 08.15~09.20 | 2500 | 2AR-FSE | AVE35 | RN1244VLRN1244VRRN1258VRN1244VSET | PN1550PN1547 | RN1438 | PN1846PN1868 | FN0659 |
| 09.15~04.18 | 2000 | 8AR-FTS | ARS210 | RN1258V | PN1550 | RN1438 | PN1846 | FN0659 |
| 07.14~04.18 | 2500 | 2AR-FSE | AWS211 | RN1258V | PN1550 | RN1438 | PN1846 | FN0659 |
| 06.01~12.12 | 2500 | 4GR-FSE | GRS200 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 02.08~12.12 | 3000 | 3GR-FE | GRS202R | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 06.04~02.08 | 4300 | 3UZ-FE | UZS186 | RN1258V | PN1479 | PN1494 | ||
| 06.04~02.08 | 4300 | 3UZ-FE | UZS187 | RN1258V | PN1479 | PN1494 |
| 12.03~02.08 | 2500 | 4GR-FSE | GRS180 | RN1536VRN1258VRN1536VSET | PN1550PN1479 | RN1665V | PN1494 | |
| 12.03~02.08 | 2500 | 4GR-FSE | GRS181 | RN1258VRN1536V | PN1479PN1550 | RN1665VRN1438 | PN1494 | FN0659 |
| 11.04~02.08 | 3000 | 3GR-FSE | GRS182 | RN1258VRN1536V | PN1479PN1550 | RN1665VRN1438 | PN1494 | FN0659 |
| 09.03~02.08 | 3000 | 3GR-FSE | GRS182R | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 01.03~01.08 | 3000 | 3GR-FSE | GRS183 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 12.12~04.18 | 2500 | 4GR-FSE | GRS210 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 02.08~12.12 | 2500 | 4GR-FSE | GWS204 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 12.09~01.15 | 2500 | 5GR-FE | GRS208 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 02.08~12.12 | 3000 | 3GR-FSE | GRS202 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 02.08~12.12 | 3000 | 3GR-FSE | GRS203 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 11.04~09.09 | 2500 | 4GR-FSE | GRX120 | RN1536VSETRN1258VRN1536V | PN1479PN1550 | RN1438RN1665V | PN1494 | FN0659 |
| 10.06~09.09 | 2500 | 4GR-FSE | GRX125 | RN1258V | PN1550 | RN1438 | PN1494 | FN0659 |
| 10.09~08.15 | 2500 | 4GR-FSE | GRX130 | RN1258V | PN1430 | RN1438 | PN1494 | FN0659 |
| 10.09~08.12 | 2500 | 4GR-FSE | GRX135 | RN1258V | PN1430 | RN1438 | PN1494 | FN0659 |
| 11.04~09.09 | 3000 | 3GR-FSE | GRX121 | RN1258VRN1536V | PN1550PN1479 | RN1665VRN1438 | PN1494 | FN0659 |
