PERFORMANCE ROTOR DISC » RN1244DSET
Specification
Outter Ø
334
Num. of holes
5
Disc Thickness (Max)
30
Height
51
Centering Diameter
62
Pitch Circle Ø
114.3
Disc Thickness (Min)
27
Drum Ø:
143
Type 1:
Vented
Structure Material
GG20
Variation
Alternative
Cross Reference
LEXUS
4351222260
LEXUS
4351622010
TOYOTA
43512-22260
TOYOTA
43512-22261
TOYOTA
43512-30350
TOYOTA
43512-30351
TOYOTA
43516-22010
TOYOTA
43516-22011
TOYOTA
43516-30040
TOYOTA
43516-30041
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 12.11~10.15 | 2500 | 4GR-FSE | GRL11 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 12.11~10.15 | 2500 | 4GR-FSE | GRL11R | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 01.05~12.11 | 3000 | 3GR-FE | GRS190 | RN1244VRRN1244VSETRN1244VL | PN1547PN1479 | RN1665V | PN1494 | FN0659 |
| 01.05~12.11 | 3000 | 3GR-FSE | GRS190 | RN1244VSETRN1244VRRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 03.12~07.20 | 3500 | 22GRFXE | GWL10 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 08.05~12.11 | 3500 | 2GR-FSE | GRS191 | RN1244VSETRN1244VRRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 01.05~09.08 | 4300 | 3UZ-FE | UZS190 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 01.05~09.08 | 4300 | 3UZ-FE | UZS190R | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1494 | FN0659 |
| 02.06~12.11 | 3500 | 2GR-FSE | GWS191 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 03.12~07.20 | 3500 | 2GR-FXE | GWL10 | RN1244VRRN1244VLRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 04.09~07.15 | 3000 | 3GR-FE | GSE22 | RN1244VLRN1244VRRN1244VSETRN1258V | PN1829PN1547 | RN1665V | PN1494PN1846 | FN0659 |
| 08.05~04.13 | 3500 | 2GR-FSE | GSE21 | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1494 | FN0659 |
| 04.13~ | 3500 | 2GR-FSE | GSE31 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1846 | FN0699 |
| 04.13~09.20 | 3500 | 2GR-FSE | GSE31L | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | PN1846 | FN0699 |
| 08.15~09.20 | 3500 | 2GR-FSE | GSE37L | RN1244VLRN1244VRRN1244VSET | PN1547 | RN1665V | PN1846 | FN0699 |
| 02.08~12.12 | 3500 | 2GR-FSE | GRS204 | RN1244VSETRN1244VRRN1244VL | PN1547 | RN1665V | PN1494 | FN0659 |
| 12.12~04.18 | 3500 | 2GR-FSE | GRS214 | RN1244VRRN1244VSETRN1244VL | PN1547 | RN1665V | FN0659 | |
| 02.08~02.13 | 3500 | 2GR-FSE | GWS204 | RN1244VSETRN1244VLRN1244VR | PN1547 | RN1665V | PN1494 | FN0659 |
