NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1606V

ROTOR DISC » RN1606V

Specification

Type

Vented

Outter Ø

275

Num. of holes

5

Disc Thickness (Max)

26

Height

47

Centering Diameter

69

Pitch Circle Ø

114.3

Front/Rear

Front

Drum Ø:

143

Disc Thickness (Min)

24

Structure Material

G3000

Cross Reference

HYUNDAI

517122H000

HYUNDAI / KIA

517122H000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Avante / Elantra 06

11.06~12.11	1600	D4FB	HD06 SDN LHD	RN1606V	PN0377	RN1307	PN0539 FN11189	FN11004
04.06~09.11	1600	G4FC	HD06 LHD	RN1606V	PN0377	RN1307	PN0539 PN0591	FN11004
11.06~09.11	1600	G4FC	HD06 RHD	RN1606V	PN0377	DN1503 RN1307	FN11189 PN0539	FN11004
04.06~01.07	1600	G4FC	PA06 RHD	RN1606V	PN0377	RN1307	PN0539	FN11004
04.06~06.11	2000	G4GC	PHD06 LHD US/CAN	RN1606V	PN0377	RN1307 DN1503	PN0591 FN11189	FN11004
04.06~06.11	2000	G4GC	PHD06 RHD	RN1606V	PN0377	RN1307 DN1503	FN11189 PN0539	FN11004
