ROTOR DISC » RN1592V
Specification
Type
Vented
Outter Ø
257
Num. of holes
4/6
Disc Thickness (Max)
22
Height
40.5
Centering Diameter
60
Pitch Circle Ø
100
Front/Rear
Front
Disc Thickness (Min)
20
Drum Ø:
126
Structure Material
G3000
Cross Reference
BENDIX
562305B
FIAT
55700920
FIAT
55700921
GM
13317922
GM
93169288_RN
GM
93188917
GM
93197241
OEM
0055700920
OEM
569024
OPEL
05 69 024
OPEL
05 69 065
OPEL
15 15 074_RN
OPEL
569024
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.05~01.10 | 1200 | 199 | RN1592V | PN0211W | DN1564 | FN0624 | ||
| 01.05~01.10 | 1300 | 199 | RN1592V | PN0187WPN0211W | FN0624 | |||
| 01.05~01.11 | 1400 | 350 A1.000 | 199.233.0.0 | RN1592V | PN0211W | DN1563 | PN0481FN0624 | |
| 01.05~12.08 | 1400 | 350 A1.000 | 199.253.0.0 | RN1592V | PN0211W | DN1563 | FN0624 |
| 03.12~ | 3/5DR HB | RN1592V | PN0187WPN0658W | DN1563 | FN0682PN0481WFN0624 | |||
| 12.13~ | 900 | 199 B6.000 | 3/5DR HB | RN1592V | PN0658WPN0187W | DN1563 | FN0624PN0481WFN0682 | |
| 03.12~ | 900 | 312 A2.000 | 3/5DR HB | RN1592V | PN0187WPN0658W | DN1563 | PN0481WFN0682FN0624 | |
| 03.12~ | 1200 | 169 A4.000 | 3/5DR HB | RN1592V | PN0658WPN0187W | DN1563 | PN0481WFN0682FN0624 | |
| 03.12~ | 1300 | 199 B4.000 | 3/5DR HB | RN1592V | PN0658WPN0187W | DN1563 | FN0682FN0624PN0481W | |
| 03.12~ | 1400 | 350 A1.000 | 5DR HB EU | RN1592V | PN0658W | DN1563 | FN0682 |
| 10.09~12.11 | 1400 | 350 A1.000 | 19923L351870 | RN1592V | PN0211W | DN1563 | FN0624 | |
| 10.09~12.11 | 1400 | 350 A1.000 | 19925L351870 | RN1592V | PN0658W | DN1563 | PN0481WFN0624 | |
| 01.09~12.11 | 1400 | 955 A6.000 | 19925H351870 | RN1592V | PN0658W | DN1563 | FN0682 |
| 07.14~ | 1000 | B10XFL | 3DR HB | RN1592V | PN34004 | DN1564DN1563 | FN0624FN0682 | |
| 07.14~ | 1200 | A12XEL | 3DR HB | RN1592V | PN34004 | DN1564DN1563 | FN0682FN0624 | |
| 07.14~ | 1200 | B12XEL | 3DR HB | RN1592V | PN34004 | DN1563DN1564 | FN0682FN0624 | |
| 07.14~ | 1400 | A14XEL | 3DR HB | RN1592V | PN34004 | DN1563DN1564 | FN0624FN0682 | |
| 07.14~ | 1400 | A14XER | 3DR HB | RN1592V | PN34004 | DN1563DN1564 | FN0624FN0682 | |
| 07.14~ | 1400 | B14NET | 3DR HB | RN1592V | PN34004 | DN1564DN1563 | FN0682FN0624 | |
| 01.13~03.19 | 1400 | B14XEL | 3DR HB | RN1592V | PN34004PN0211W | DN1563DN1564 | FN0682FN0624 |
| 09.06~09.14 | 1000 | Z10XEP | RN1592V | PN0211W | DN1564DN1563 | PN0481FN0624FN0682 | ||
| 05.06~11.14 | 1200 | Z12XEP | S07 | RN1592V | PN0211W | DN1564DN1563 | FN0624FN0682 | |
| 09.06~09.14 | 1300 | Z13DT# | RN1592V | PN0211W | DN1564DN1563 | FN0624 | ||
| 05.06~11.14 | 1400 | A14XER | S07 | RN1592V | PN0211W | DN1563 | FN0624 | |
| 05.06~11.14 | 1400 | Z14XEP | S07 | RN1592V | PN0211W | DN1563 | FN0624 |
