DRUM BRAKE » DN1563
Specification
Outter Ø
269
Num. of holes
4
Hole Ø
14
Centering Diameter
60
Height
61
Pitch Circle Ø
100
Drum Ø
228.3
Structure Material
G3000
Cross Reference
FIAT
51901443
FIAT
51901444
FIAT
55701380
FIAT
55703043
FIAT
55704058
GM
13423796
GM
55701380
GM
55704058
OPEL
05 68 000
OPEL
0568003
OPEL
13423796
OPEL
568270
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.05~01.11 | 1400 | 350 A1.000 | 199.233.0.0 | RN1592V | PN0211W | DN1563 | PN0481FN0624 | |
| 01.05~12.08 | 1400 | 350 A1.000 | 199.253.0.0 | RN1592V | PN0211W | DN1563 | FN0624 |
| 03.12~ | 3/5DR HB | RN1592V | PN0187WPN0658W | DN1563 | FN0624FN0682PN0481W | |||
| 12.13~ | 900 | 199 B6.000 | 3/5DR HB | RN1592V | PN0187WPN0658W | DN1563 | FN0682FN0624PN0481W | |
| 03.12~ | 900 | 312 A2.000 | 3/5DR HB | RN1592V | PN0658WPN0187W | DN1563 | FN0624PN0481WFN0682 | |
| 03.12~ | 1200 | 169 A4.000 | 3/5DR HB | RN1592V | PN0187WPN0658W | DN1563 | FN0682FN0624PN0481W | |
| 03.12~ | 1300 | 199 B4.000 | 3/5DR HB | RN1592V | PN0658WPN0187W | DN1563 | PN0481WFN0682FN0624 | |
| 03.12~ | 1400 | 350 A1.000 | 5DR HB EU | RN1592V | PN0658W | DN1563 | FN0682 |
| 10.09~12.11 | 1300 | 199 A9.000 | 199 | PN0187W | DN1563 | FN0624 | ||
| 10.09~12.11 | 1400 | 350 A1.000 | 19923L351870 | RN1592V | PN0211W | DN1563 | FN0624 | |
| 10.09~12.11 | 1400 | 350 A1.000 | 19925L351870 | RN1592V | PN0658W | DN1563 | PN0481WFN0624 | |
| 01.09~12.11 | 1400 | 955 A6.000 | 19925H351870 | RN1592V | PN0658W | DN1563 | FN0682 |
| 07.14~ | 1000 | B10XFL | 3DR HB | RN1592V | PN34004 | DN1563DN1564 | FN0624FN0682 | |
| 07.14~ | 1200 | A12XEL | 3DR HB | RN1592V | PN34004 | DN1564DN1563 | FN0682FN0624 | |
| 07.14~ | 1200 | B12XEL | 3DR HB | RN1592V | PN34004 | DN1563DN1564 | FN0624FN0682 | |
| 07.14~ | 1400 | A14XEL | 3DR HB | RN1592V | PN34004 | DN1563DN1564 | FN0624FN0682 | |
| 07.14~ | 1400 | A14XER | 3DR HB | RN1592V | PN34004 | DN1564DN1563 | FN0624FN0682 | |
| 07.14~ | 1400 | B14NET | 3DR HB | RN1592V | PN34004 | DN1564DN1563 | FN0682FN0624 | |
| 01.13~03.19 | 1400 | B14XEL | 3DR HB | RN1592V | PN0211WPN34004 | DN1564DN1563 | FN0624FN0682 |
| 09.06~09.14 | 1000 | Z10XEP | RN1592V | PN0211W | DN1564DN1563 | PN0481FN0624FN0682 | ||
| 05.06~11.14 | 1200 | Z12XEP | S07 | RN1592V | PN0211W | DN1564DN1563 | FN0624FN0682 | |
| 09.06~09.14 | 1300 | Z13DT# | RN1592V | PN0211W | DN1563DN1564 | FN0624 | ||
| 05.06~11.14 | 1400 | A14XER | S07 | RN1592V | PN0211W | DN1563 | FN0624 | |
| 05.06~11.14 | 1400 | Z14XEP | S07 | RN1592V | PN0211W | DN1563 | FN0624 |
