ROTOR DISC » RN21002V

Specification

Type
Vented
Outter Ø
309
Num. of holes
5
Disc Thickness (Max)
18
Height
70
Centering Diameter
62
Front/Rear
Rear
Pitch Circle Ø
114.3
Drum Ø:
210
Structure Material
G3000
Disc Thickness (Min)
16.5

Cross Reference

LEXUS
42431-48080
TOYOTA
42431-48080
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.08~10.15 3500 2GR-FE GGL15 RN1443V PN1845 RN21002VRN1473 PN1846 FN0651
03.09~10.15 3500 2GR-FXE GYL15 RN1578VRN1443V PN1845 RN1473RN21002V PN1846 FN0651

Exemption from liability: the catalog data is advisory and can be used for reference only
