ROTOR DISC » RN2298V

Specification

Type
Vented
Outter Ø
280
Num. of holes
5
Hole Ø:
12.8
Disc Thickness (Max)
24
Disc Thickness (Min)
22
Height
44
Centering Diameter
68
Pitch Circle Ø
114.3
Drum Ø:
139.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

NISSAN
40206-6LA0A
NISSAN
40206-6LE0A
RENAULT
40 20 620 72R
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.20~ 1000 HR10DDT F16E AR RN2298V PN2017 RN2428DN1625
07.22~ 1200 HR12DE P15JPN RN2298V PN2017 RN2455 PN2015
03.20~ 1200 HR12DE P15T RN2298V PN2017 RN2455 PN2015
03.20~07.22 1200 HR12DE P15T JPN RN2298V PN2017 RN2455 PN2015
05.17~ 1500 HR15DE P15T RN2357VRN2298V PN2017PN2005 FN0761PN2006
04.16~ 1600 HR16DE CP5CU US RN2298VRN2357V PN2005PN2017 DN1290 FN0761PN2006
11.19~ 2000 MR20DD B18X RN2298V PN2017 DN1311RN2373 PN2016FN0729
05.19~ 1600 HR16 B18ZGL RN2298V PN2017 DN1311RN2373RN2455 FN0729PN2016
03.21~ 1300 H5H455 LDM3 RHD AUL RN2298V PN0551 RN2373 PN0730

Exemption from liability: the catalog data is advisory and can be used for reference only
