DRUM BRAKE » DN1290

Specification

Outter Ø
245
Num. of holes
4
Centering Diameter
61
Height
59.7
Pitch Circle Ø
100
Drum Ø
203.3
Structure Material
G3000
Hole Ø
12.8

Cross Reference

NISSAN
43206-5RB0A
NISSAN
43206-5RB0B
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.16~ 1600 HR16DE CP5C9 RN2357V PN2005 DN1290 FN0761PN2006
04.16~ 1600 HR16DE CP5CU US RN2298VRN2357V PN2017PN2005 DN1290 FN0761PN2006
04.17~02.18 1600 HR16DE P15B RN2357V PN2005 DN1290 FN0761
03.18~ 1600 HR16DE P15X RN2357V PN2005 DN1290 FN0761
08.19~ 1600 HR16DE N18X GL RN2357V PN2005 DN1290 FN0761
06.19~ 1600 HR16DE N18X US RN2357V PN2005 DN1290 FN0761
06.19~ 1600 HR16DE N18X US RN2357V PN2005 DN1290 FN0761

Exemption from liability: the catalog data is advisory and can be used for reference only
