DRUM BRAKE » DN1607

Specification

Outter Ø
208
Num. of holes
4
Centering Diameter
53.5
Height
83
Pitch Circle Ø
100
Drum Ø
180
Structure Material
G3000
Hole Ø
M12x1,5
Notes
w/o Wheel Bearing, w/o ABS Speed Sensor

Cross Reference

RENAULT
60 01 548 126
RENAULT
77 00 419 824
RENAULT
77 00 752 363
RENAULT
77 00 783 030
RENAULT
77 01 463 277
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.98~06.01 1200 D7F720 BB0A 5DR HB RN1002VRN1000RN1037V PN0284W DN1609HDN1607 FN0602FN0619FN0778
10.85~12.96 1400 C3J7# B407 RN1000 PN0284W DN1607 FN0524
03.93~10.96 1200 C3G 70# C06 RN1001 PN0240 DN1607 FN0521

Exemption from liability: the catalog data is advisory and can be used for reference only
