ROTOR DISC » RN1001

Specification

Type
Solid
Disc Thickness (Max)
8.2
Num. of holes
4
Height
41
Centering Diameter
61
Pitch Circle Ø
100
Outter Ø
238
Front/Rear
Rear
Disc Thickness (Min)
7
Drum Ø:
129
Structure Material
G3000

Cross Reference

BENDIX
561257B
OEM
8427371
RENAULT
7700716947
RENAULT
7701204285
RENAULT
7701716947
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.96~09.98 1100 D7F73# 3/5 DR HB RN1001 PN0284W FN9690
06.87~04.96 1100 C1E 7 B40 RN1001 PN0240 FN0521
06.87~04.96 1100 C1E 7 C40# RN1001 PN0240 FN0521
06.87~04.96 1100 C1E 7 S401 RN1001 PN0240 FN0521
10.86~04.96 1600 F8M730 B404 RN1001RN1002V PN0240PN0284W FN0521FN0504
10.86~04.96 1600 F8M730 C404 RN1001RN1002V PN0284WPN0240 FN0504FN0521
03.93~10.96 1200 C3G 70# C06 RN1001 PN0240 DN1607 FN0521
05.96~06.07 1200 D7F70# 3DR HB / LCV RN1037VRN1001RN1191 PN0240PN0284W FN0521FN0602

Exemption from liability: the catalog data is advisory and can be used for reference only
