DRUM BRAKE » DN1546

DN1546

Specification

Outter Ø
290
Num. of holes
4
Hole Ø
13.7
Centering Diameter
65
Height
57.6
Pitch Circle Ø
100
Drum Ø
230
Structure Material
G3000

Cross Reference

SEAT
6K9 609 617
VAG
6K9 609 617
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

VOLKSWAGEN   »   Caddy II

11.97~09.00 1400 AKV 9K9BA1 RN1013RN1280V PN0023W DN1546DN1537DN1536 FN0537FN0554
12.97~06.03 1400 APQ 9K9___ RN1280VRN1013 PN0023W DN1537DN1546DN1536 FN0554FN0537
09.00~06.03 1400 AUA 9K9_E6 RN1280V PN0023W DN1546 FN0554
09.00~06.03 1400 AUD 9K9_D_ RN1280V PN0023W DN1546 FN0554
06.97~09.00 1600 AEE 9K9_5_ RN1280V PN0023W DN1546DN1536DN1537 FN0537FN0554
07.96~09.00 1700 AHB 9K9_21 RN1280VRN1013 PN0023W DN1546DN1536DN1537 FN0554FN0537
11.95~06.03 1900 1Y 9K9_Y1 RN1013RN1280V PN0023WPN0018 DN1546DN1536DN1537 FN0554FN0537
11.95~09.00 1900 AEY 9K9_Z1 RN1013RN1280V PN0018PN0023W DN1536DN1537DN1546 FN0554FN0537
10.96~09.00 1900 AHU 9K9_N_ RN1013RN1280V PN0023W DN1536DN1537DN1546 FN0537FN0554
09.97~09.00 1900 ALE 9K9BH1 RN1013RN1280V PN0023W DN1536DN1537DN1546 FN0537FN0554
09.00~06.03 1900 ALH 9K9_N_ RN1280V PN0018 DN1546 FN0554
09.00~06.03 1900 AYQ 9K9_36 RN1280V PN0023W DN1546 FN0554
