NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1426

DRUM BRAKE » DN1426

Specification

Outter Ø

340

Num. of holes

6

Hole Ø

12.7

Centering Diameter

101

Height

80.5

Pitch Circle Ø

139.7

Drum Ø

295

Structure Material

G3000

Cross Reference

ISUZU

8-97238-630-1

ISUZU

8-97360-506-0

ISUZU

8-98030-385-0

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CHEVROLET (GM) » LUV

06.03~01.13

2400

LG1/C24SE

DL33P

RN1327V RN24001V

PN4801

DN1426 DN1439

FN4470 FN4467

ISUZU » Alterra

03.05~10.13

3000

4JJ1-TC

UCR85

RN1327V

PN0822 PN4801

DN1426

FN4467

ISUZU » D-Max

01.04~01.11	2500	4JA1-T	TF_54	RN1327V	PN0822	DN1426 DN1439	FN4470 FN4467
10.08~12.11	2500	4JK1-TCX	TF_86	RN1327V	PN0822	DN1426	FN4467
01.02~01.07	3000	4JH1	TF_77	RN1326V RN1327V	PN4801	DN1426	FN4467
01.09~12.11	3000	4JJ1-TCS	TFS85H RHD	RN1327V	PN0822	DN1426	FN4467
08.08~	3000	4JJ1-TCS	TF_85	RN1327V	PN0822	DN1426	FN4467
06.03~	3000	4JJ1-TCX	TFS85	RN1327V	PN4801	DN1426	FN4467

ISUZU » Pickup TFR

01.04~01.11	2500	4JA1-T	TFS54H	RN1327V	PN4801	DN1426	FN4467
10.08~07.10	2500	4JK1-TCX	TFR86	RN1327V	PN0822	DN1426	FN4467
01.04~09.12	3000	4JH1-TC	TFS77HDK	RN1327V	PN4801	DN1426	FN4467
01.04~12.11	3000	4JJ1-TCS	TFS85H RHD	RN1327V	PN4801	DN1426	FN4467
