DRUM BRAKE » DN1244
Specification
Outter Ø
235
Num. of holes
4
Hole Ø
14.5
Centering Diameter
55
Height
65.4
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Cross Reference
GM
19171661
GM
89027321
GM
94852720
TOYOTA
42431-02020
TOYOTA
42431-12130
TOYOTA
42431-12180
TOYOTA
42431-20250
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.92~08.96 | 1500 | 5A-FE | AT192 | RN1484VRN1058V | PN1322PN1077 | DN1249DN1244 | FN2285 | |
| 08.96~08.01 | 1500 | 5A-FE | AT212 | RN1058VRN1484V | PN1322PN1077 | DN1249DN1244 | FN2311 | |
| 08.92~08.96 | 1600 | 4A-FE | AT190 | RN1058V | PN1322 | DN1249DN1244 | FN2285 | |
| 08.94~06.97 | 1800 | 7A-FE | AT191 | RN1058V | PN1322 | DN1244DN1249 | FN2285 |
| 05.92~04.97 | 1300 | 2E | EE100L | RN2111V | PN1077 | DN1244 | FN2311 | |
| 08.91~11.01 | 1300 | 2E | EE100R | RN2111V | PN1077 | DN1244 | FN2311 | |
| 04.95~09.01 | 1300 | 2E | EE110L | RN2111V | PN1077 | DN1244 | FN2311 | |
| 06.91~05.95 | 1300 | 4E-FE | EE101 | RN2111V | PN1077 | DN1244 | FN2311 | |
| 01.95~12.04 | 1300 | 4E-FE | EE111 | RN2111V | PN1077 | DN1244 | FN2311 | |
| 05.95~03.03 | 1500 | 5A-FE | AE110 | RN2111V | PN1077 | DN1244 | FN2311 | |
| 08.91~05.97 | 1600 | 4A-FE | AE101R HB/LB | RN1250VRN1483V | PN1077 | DN1244 | FN2311 | |
| 08.91~11.01 | 1600 | 4A-FE | AE101R SDN | RN1250V | PN1322 | DN1244 | FN2311 | |
| 01.95~12.04 | 1600 | 4A-FE | AE111 | RN1250VRN1483V | PN1077PN1322 | DN1244 | FN2311PN1321 | |
| 04.97~08.02 | 1600 | 4A-FE | AE111L | RN2111V | PN1322PN1077 | DN1244RN1228 | PN1321FN2285FN2311 | |
| 05.95~07.02 | 1600 | 4A-FE | AE111R | RN1364V | PN1322PN1077 | DN1244RN1228 | FN2311FN2285PN1321 | |
| 05.00~01.02 | 1800 | 1ZZ-FE | ZZE110L | RN1364V | PN1302 | DN1244 | FN2285 | |
| 06.91~05.95 | 2000 | 2C | CE100 | RN1250V | PN1322PN1077 | DN1244 | FN2311 | |
| 05.95~04.98 | 2000 | 2C | CE100G | RN1250V | PN1077 | DN1244 | FN2311 | |
| 05.95~04.98 | 2000 | 2C | CE110 | RN1250V | PN1077 | DN1244 | FN2311 | |
| 04.98~08.00 | 2200 | 3C-E | CE113 | RN1250V | PN1077 | DN1244 | FN2311 |
| 06.91~08.98 | 1500 | 5A-FE | AE100 | RN1250V | PN1077 | DN1244 | FN2311 | |
| 05.95~08.00 | 1500 | 5A-FE | AE110 | RN2111V | PN1077 | DN1244 | FN2311 | |
| 06.91~08.98 | 1600 | 4A-FE | AE101 | RN1483V | PN1077 | DN1244 | FN2311 | |
| 05.95~08.00 | 1600 | 4A-FE | AE111 | RN1483V | PN1077 | DN1244 | FN2311 |
| 06.91~05.95 | 1300 | 4E-FE | EE101 | PN1077 | DN1244 | FN2311 | ||
| 05.95~08.00 | 1300 | 4E-FE | EE111 | PN1077 | DN1244 | FN2311 | ||
| 06.91~05.95 | 1500 | 5A-FE | AE100 | RN1250V | PN1077 | DN1244 | FN2311 | |
| 05.95~08.00 | 1500 | 5A-FE | AE110 | RN2111V | PN1077 | DN1244 | FN2311 | |
| 06.91~08.98 | 1600 | 4A-FE | AE101 | RN1483V | PN1077 | DN1244 | FN2311 | |
| 05.95~08.00 | 1600 | 4A-GE | AE111G | RN1245V | PN1077 | DN1244RN1228 | PN1321 | |
| 09.91~05.95 | 2000 | 2C | CE100G | DN1244 | FN2311 | |||
| 05.95~04.98 | 2000 | 2C | CE110 | RN1250V | PN1077 | DN1244 | FN2311 | |
| 04.98~08.00 | 2200 | 3CE | CE113 | PN1077 | DN1244 | FN2311 |
