ROTOR DISC » RN1527V

Specification

Type
Vented
Disc Thickness (Max)
30
Num. of holes
5
Height
57
Centering Diameter
58
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
316
Drum Ø:
148.7
Disc Thickness (Min)
28
Structure Material
G3000
Hole Ø:
13

Cross Reference

SUBARU
26300-AL010
SUBARU
26300-AL03A
SUBARU
26300-AL04A
SUBARU
26300-FG000
SUBARU
26300-XA00A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.04~01.14 3000 EZ30 WXE RHD RN1527V PN7499 RN1528V PN7803 FN0651
04.04~07.07 3000 EZ30D WX85 LHD US RN1527V PN7499 RN1528V PN7803 FN0651
03.06~01.14 3000 EZ30D WXE LHD EU RN1527V PN7499 RN1528V PN7803 FN0651
04.07~01.14 3600 EZ36D WX EA LHD EU RN1527V PN7499 RN1528V PN7803 FN0651
04.07~01.14 3600 EZ36D WX KS LHD GCC RN1527V PN7499 RN1528V PN7803 FN0651
04.07~01.14 3600 EZ36D WXF KA RHD RN1527V PN7499 RN1528V PN7803 FN0651
03.13~ 2000 FA20E VAG RN1527V PN7499 PN7501 FN0755
05.12~10.14 2500 EJ25 GJ9 RN1527VRN1122V PN7463
03.15~08.20 2000 EE20Z BS RN1527V PN7499 RN1691V PN7804
08.14~09.21 2500 FB25A BS9 JPN RN1527V PN7499 RN1691V PN7804
08.14~08.20 2500 FB25A BS9K RN1527V PN7499 RN1691V PN7804
08.14~10.17 2500 FB25B BSBHC US RN1527V PN7499 RN1691V PN7804
08.14~08.20 3600 EZ36D BSF RN1527V PN7499 RN1691V PN7804
12.13~08.20 1600 FB16E VM4 JPN RN1527V PN7499 RN1691V PN7804
12.13~ 1600 FB16E VM4BK25 RN1527V PN7499 RN1691V PN7804
04.17~ 1600 FB16E VM4DK15 RHD RN1527V PN7499 RN1691V PN7804
06.14~ 2000 FA20E VMG RN1527V PN7499 RN1691V PN7804

Exemption from liability: the catalog data is advisory and can be used for reference only
