ROTOR DISC » RN1691V
Specification
Type
Vented
Num. of holes
5
Front/Rear
Rear
Outter Ø
300
Disc Thickness (Max)
17
Height
46.4
Centering Diameter
58
Pitch Circle Ø
114.3
Drum Ø:
166
Disc Thickness (Min)
15
Structure Material
G3000
Cross Reference
SUBARU
26700-AL010
SUBARU
26700-AL03A
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.24~ | 2000 | FB20W | SL | RN2438V | PN7805 | RN1691V | PN7804 | |
| 01.24~ | 2500 | FB25D | SL9 | RN2438V | PN7805 | RN1691V | PN7804 |
| 10.14~08.20 | 2500 | FB25A | BN9 JPN | RN2243V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 2500 | FB25A | BN9 RHD | RN2243V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 2500 | FB25B | BN9AL LHD | RN2243V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 2500 | FB25B | BN9BL LHD | RN2243V | PN7499 | RN1691V | PN7804 | |
| 08.20~ | 2500 | FB25D | BW# | RN2438V | PN7805 | RN1691V | PN7804 |
| 10.21~ | 1800 | CB18E | BT5 | RN2438V | PN7805 | RN1691V | PN7804 | |
| 03.15~08.20 | 2000 | EE20Z | BS | RN1527V | PN7499 | RN1691V | PN7804 | |
| 05.19~ | 2400 | FA24F | BTG | RN2438V | PN7805 | RN1691V | PN7804 | |
| 08.14~09.21 | 2500 | FB25A | BS9 JPN | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 2500 | FB25A | BS9K | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~10.17 | 2500 | FB25B | BSBHC US | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.20~ | 2500 | FB25D | BT# | RN2438V | PN7805 | RN1691V | PN7804 | |
| 08.14~08.20 | 3600 | EZ36D | BSF | RN1527V | PN7499 | RN1691V | PN7804 |
| 12.13~08.20 | 1600 | FB16E | VM4 JPN | RN1527V | PN7499 | RN1691V | PN7804 | |
| 12.13~ | 1600 | FB16E | VM4BK25 | RN1527V | PN7499 | RN1691V | PN7804 | |
| 04.17~ | 1600 | FB16E | VM4DK15 RHD | RN1527V | PN7499 | RN1691V | PN7804 | |
| 10.20~ | 1800 | CB18E | VN5 JPN | RN2169V | PN7805 | RN1691V | PN7804 | |
| 06.14~ | 2000 | FA20E | VMG | RN1527V | PN7499 | RN1691V | PN7804 | |
| 11.21~ | 2400 | FA24E | VNH | RN2169V | PN7805 | RN1691VRN2448V | PN7804PN7803 | FN0755 |
