BRAKE PADS » PN1142
Specification
Length-1
125.4
Width-1
42.4
Thickness-1
14.7
Pcs In Set
4
Cross Reference
AKEBONO
A-353K
AKEBONO
AN-353
AKEBONO
AN-353K
BENDIX
DB1244
BENDIX AUS
DB413
BENDIX EUR
572264B
FMSI
D304
FMSI
D304-7206
FMSI
D337
FMSI
D337-7206
FMSI
D432
FMSI
D432-7319
FMSI
D622
FMSI
D622-7319
HITACHI
NDP171
KASHIYAMA
D2042
KASHIYAMA
D2062
KASHIYAMA
D206202
MAZDA
1Y02-26-48Z
TOYOTA
04466-14010
TOYOTA
04466-14017
TOYOTA
04466-22030
TOYOTA
04466-22040
TOYOTA
04466-22070
TOYOTA
04466-22090
TOYOTA
04466-22110
TOYOTA
04466-22200
TOYOTA
04466-30010
TOYOTA
04466-40010
TOYOTA
04466-40030
TOYOTA
04492-14080
TOYOTA
04492-14081
TOYOTA
04492-14090
TOYOTA
04492-14100
TOYOTA
04492-14110
TOYOTA
04492-14120
TOYOTA
04492-14130
TOYOTA
04492-22030
TOYOTA
04492-22040
TOYOTA
04492-22041
TOYOTA
04492-22042
TOYOTA
04492-22043
TOYOTA
04492-22050
TOYOTA
04492-22060
TOYOTA
04492-22070
TOYOTA
04492-22080
TOYOTA
04492-22090
TOYOTA
04492-22092
TOYOTA
04492-22100
TOYOTA
04492-22101
TOYOTA
04492-22110
TOYOTA
04492-22111
TOYOTA
04492-22120
TOYOTA
04492-22121
TOYOTA
04492-22140
TOYOTA
04492-22141
TOYOTA
04492-30080
TOYOTA
04492-30100
TOYOTA
04492-30101
TOYOTA
04492-30110
TOYOTA
04492-30120
TOYOTA
04492-30130
TOYOTA
04492-40010
TOYOTA
04492-40020
TOYOTA
04492-40030
TOYOTA
AY060-TY004
TOYOTA
V9118-2013
TOYOTA
V9118-B013
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.88~12.95 | 2000 | 1G-FE | GX81 | RN1301V | PN1246 | PN1142FN2220 | ||
| 08.90~02.93 | 2500 | 1JZ-G#E | JZX81 | PN1246 | PN1142 | FN0669 | ||
| 08.89~10.92 | 3000 | 7M-GE | MX83 | PN1246 | PN1142FN2220 |
| 01.89~10.92 | 2000 | X6 | PN1246 | PN1142 | ||||
| 08.80~07.84 | 2000 | 21R | RX60 | PN1246 | PN1142 | |||
| 01.89~10.92 | 2200 | L | X60 | RN1301V | PN1246 | PN1142 | ||
| 01.89~12.96 | 2400 | 22R | RX81 | RN1301V | PN1246 | PN1142 | FN0669 | |
| 01.89~10.92 | 2400 | 2L-T | X60 | RN1301V | PN1246 | PN1142 | ||
| 08.84~12.92 | 2800 | 5M-GE | MX73L | RN1826V | PN1071 | PN1142 | FN21001 | |
| 12.88~05.92 | 3000 | 7M-GE | MX75R | RN1826V | PN1071 | PN1142 | FN21001 | |
| 08.88~02.93 | 3000 | 7M-GE | MX83L | PN1246 | PN1142 | FN0669 |
| 08.88~10.92 | 2000 | 1G-FE | GX81 | RN1301V | PN1246 | PN1142 | FN0669 | |
| 08.88~08.90 | 2000 | 1G-GTE | GX81 | PN1246 | PN1142 | FN0669 | ||
| 10.85~08.88 | 2000 | 1G-GTEU | GX71 | PN1071 | PN1142 | FN21001 | ||
| 08.90~10.92 | 2500 | 1JZ-GE | JZX81 | PN1246 | PN1142 | FN0669 | ||
| 08.89~10.92 | 3000 | 7M-GE | MX83 | PN1246 | PN1142 |
| 08.83~08.87 | 2000 | GS121 | PN1052 | PN1142 | FN21001 | |||
| 09.87~12.95 | 2000 | GS141 | PN1157 | PN1142 | ||||
| 08.83~08.87 | 2000 | MS120 | PN1052 | FN2252PN1142 | FN21001 | |||
| 08.83~08.88 | 2000 | 1G-EU | GS120 | PN1052 | RN1488V | PN1142FN2252 | ||
| 09.88~12.95 | 2000 | 1G-FE | GS130 | RN1828V | PN1157 | PN1142FN2252 | ||
| 01.88~12.95 | 2000 | 1G-FE | GS131 | RN1828V | PN1157 | PN1142 | FN21001 | |
| 08.89~12.95 | 2000 | 1G-FE | GS131R | RN1828V | PN1157 | PN1142 | FN21001 | |
| 08.93~07.95 | 2000 | 1G-FE | GS141 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 09.87~12.95 | 2000 | 1G-GZE | GS131H | PN1157 | PN1142 | |||
| 08.83~08.87 | 2400 | LS120 | PN1052FN2251 | PN1142FN2252 | ||||
| 08.93~09.95 | 2400 | 2L-TE | LS131 | PN1157 | PN1142 | |||
| 08.89~10.91 | 2400 | 2L-THE | LS131 | RN1828V | PN1157 | PN1142 | FN21001 | |
| 10.91~08.93 | 2400 | 2L-THE | LS131H | RN1828V | PN1157 | PN1142 | FN21001 | |
| 01.91~12.95 | 2400 | 2L-THE | LS141 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 08.90~12.95 | 2500 | 1JZ-GE | JZS131 | RN1828V | PN1157 | PN1142 | ||
| 01.84~08.87 | 3000 | MS125 | PN1052 | PN1142 | ||||
| 10.91~12.95 | 3000 | 2JZ-GE | JZS133 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 10.91~12.95 | 3000 | 2JZ-GE | JZS133L | RN1490V | PN1157 | PN1142 | FN21001 | |
| 01.88~11.01 | 3000 | 2JZ-GE | JZS133R | RN1490V | PN1157 | PN1142 | FN21001 | |
| 10.91~12.95 | 3000 | 2JZ-GE | JZS135 | PN1157 | RN1487 | PN1142 | ||
| 09.87~10.91 | 3000 | 7M-GE | MS135 | RN1828V | PN1157 | PN1142 | ||
| 09.87~10.91 | 3000 | 7M-GE | MS137 | PN1157 | PN1142 | |||
| 08.89~10.91 | 4000 | 1UZ-FE | UZS131 | RN1490V | PN1157 | PN1142 |
| 10.91~08.95 | 2500 | 1JZ-GE | JZS141 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 10.91~08.95 | 3000 | 2JZ-GE | JZS143 | PN1157 | RN1487 | PN1142 | ||
| 10.91~08.95 | 3000 | 2JZ-GE | JZS145 | PN1157 | RN1487 | PN1142 |
| 08.88~10.93 | 2000 | 1G-FE | GX81 | RN1301V | PN1246 | PN1142 | ||
| 08.90~12.93 | 2500 | JZX81 | PN1246 | PN1142 | ||||
| 08.88~02.93 | 3000 | MX83 | PN1246 | PN1142 |
