ROTOR DISC » RN1490V
Specification
Type
Vented
Disc Thickness (Max)
26
Num. of holes
5
Height
38
Centering Diameter
76
Front/Rear
Front
Outter Ø
280
Pitch Circle Ø
100
Cross Reference
TOYOTA
43512-30220
TOYOTA
43512-30260
TOYOTA
4351230160
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.93~07.95 | 2000 | 1G-FE | GS141 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 01.91~12.95 | 2400 | 2L-THE | LS141 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 08.90~04.99 | 2500 | 1JZ-GE | JZS130G | RN1490V | PN1157 | FN2252 | ||
| 10.91~12.95 | 3000 | 2JZ-GE | JZS133 | RN1490V | PN1157 | PN1142 | FN21001 | |
| 10.91~12.95 | 3000 | 2JZ-GE | JZS133L | RN1490V | PN1157 | PN1142 | FN21001 | |
| 01.88~11.01 | 3000 | 2JZ-GE | JZS133R | RN1490V | PN1157 | PN1142 | FN21001 | |
| 08.89~10.91 | 4000 | 1UZ-FE | UZS131 | RN1490V | PN1157 | PN1142 |
