ROTOR DISC » RN2735

Image Not Available

Specification

Type
Solid
Outter Ø
270
Num. of holes
5
Hole Ø:
14.3
Disc Thickness (Max)
10
Disc Thickness (Min)
9
Height
32.5
Centering Diameter
65
Pitch Circle Ø
108
Drum Ø:
147.1
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GAC MOTOR
3520006ASV0000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GAC   »   Trumpchi GS4

03.16~11.19 1500 4A15M1 A28 RN2734VRN2732V PN5483 RN2735RN2733 PN51038PN0044
