ROTOR DISC » RN2732V

Image Not Available

Specification

Type
Vented
Outter Ø
281
Num. of holes
5
Hole Ø:
14.3
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
46.5
Centering Diameter
65
Pitch Circle Ø
108
Drum Ø:
145
Front/Rear
Front
Structure Material
G3000

Cross Reference

GAC MOTOR
3510010AAF00F0
GAC MOTOR
3510010AAF99F0
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GAC   »   Trumpchi GS3

08.17~03.23 1300 4A13 A5H RN2732V PN8040 RN2733 PN0846
04.22~08.23 1500 4A15J1 HT1C-TA5-00 RN2732V PN8040 RN2733 PN0846

GAC   »   Trumpchi GS4

03.16~11.19 1500 4A15M1 A28 RN2734VRN2732V PN5483 RN2735RN2733 PN51038PN0044
