ROTOR DISC » RN3007V

Specification

Type
Vented
Outter Ø
305
Num. of holes
5
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
45.7
Centering Diameter
59
Pitch Circle Ø
98
Drum Ø:
127
Front/Rear
Front
Structure Material
G3000

Cross Reference

CHRYSLER
68201086AA
FIAT
51854567
FIAT
51897455
FIAT
51914663
FIAT
52067169
FIAT
52199580
GM
95515332
OPEL
05 69 096
OPEL
5 69 087
OPEL
95511283
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.12~ 1400 198 A4.000 312 RN3007V PN41001W
01.13~ 1400 312 B3.000 352 RN3007V PN0748W PN41001W
01.09~01.15 1600 198 A3.000 263.223.0.5 RN3007V PN0187W DN1697 FN41001
01.09~01.16 1600 263 A5.000 263.216.0.5 RN3007V PN0748WPN0187W DN1697 FN41001
02.10~ 1400 843 A1.000 152.731.0.5 RN3007V PN0748W FN41001
10.15~ 1600 263 A5.000 263.216.1.5 RN1022VRN3007V PN0187WPN0748W FN41001
10.15~ 1600 263 A5.000 263.226.1.5 RN3007V PN0748W FN41001
10.15~ 1600 263 A8.000 263.223.1.5 RN3007V PN0748W FN41001
01.12~01.18 1600 A16FDH X12 RN3007V PN0748W FN41001
01.12~01.18 1600 A16FDL X12 RN3007V PN0748W FN41001

Exemption from liability: the catalog data is advisory and can be used for reference only
