ROTOR DISC » RN2068V
Specification
Type
Vented
Outter Ø
305
Num. of holes
5
Hole Ø:
14.5
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
49.5
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
158
Structure Material
G3000
Variation
Cross Reference
TOYOTA
43512-06170
TOYOTA
43512-06180
TOYOTA
43512-06200
TOYOTA
43512-33150
TOYOTA
43512-76010
TOYOTA
43512-F4030
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.18~ | 2500 | A25A-FKS | AXZA10 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 06.18~ | 2500 | A25A-FKS | AXZA10R | RN2068V | PN1857 | RN1445 | PN1854 |
| 06.18~ | 2500 | A25A-FXS | AXZH10 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 06.18~ | 2500 | A25A-FXS | AXZH10L | RN2068V | PN1857 | RN1445 | PN1854 |
| 03.19~ | 2500 | A25AFKS | AXXA55L | RN2068V | PN1857 | RN1445 | PN1854 | FN0718 |
| 05.18~ | 2500 | A25AFXS | AXXH50L | RN2068V | PN1857 | RN1445 | PN1854 | |
| 05.18~ | 2500 | A25AFXS | AXXH51L | RN2068V | PN1857 | RN1445 | PN1854 | |
| 04.18~ | 3500 | 2GR-FKS | GSX50L | RN2068V | PN1857 | RN1445 | PN1854 | FN0718 |
| 12.16~ | 1200 | 8NR-FTS | NGX50R | RN2032VRN2068V | PN1858 | RN2320RN1445 | PN1852PN1867 | |
| 10.19~ | 1800 | 2ZR-FXE | ZYX11 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 08.18~ | 2000 | M20A-FXS | MAXA10L | RN2068V | PN1857 | RN1445 | PN1854 |
| 04.18~ | 2000 | 6AR-FSE | ASV71L | RN2068V | PN1857 | RN1445 | PN1854 | |
| 03.24~ | 2000 | M20 | MXVA80 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 03.24~ | 2000 | M20 | MXVH80 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 04.21~ | 2000 | M20AFKS | MXVA71 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 09.17~04.21 | 2500 | 2AR-FE | ASV70 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 09.17~ | 2500 | 2AR-FE | ASV70L | RN2068V | PN1857 | RN1445 | PN1854 | |
| 09.17~ | 2500 | 2AR-FE | ASV70R | RN2068V | PN1857 | RN1445 | PN1854 | |
| 06.24~ | 2500 | A25 | AXVA80 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 04.24~ | 2500 | A25 | AXVH80 | RN2068V | RN1445 | PN1854 | ||
| 06.24~ | 2500 | A25 | AXVH80 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 04.24~ | 2500 | A25 | AXVH85 | RN2068V | RN1445 | PN1854 | ||
| 08.17~ | 2500 | A25-AFKS | AXVA70L | RN2068V | PN1857 | RN2570RN1445 | PN1854PN1522 | FN0621 |
| 10.18~ | 2500 | A25-AFKS | AXVA70R | RN2068V | PN1857 | RN1445 | PN1854 | |
| 08.17~ | 2500 | A25-AFXS | AXVH70 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 06.17~ | 2500 | A25-AFXS | AXVH70L | RN2068V | PN1857 | RN1445 | PN1854 | |
| 02.20~ | 2500 | A25-AFXS | AXVH70R | RN2068V | PN1857 | RN1445 | PN1854 | |
| 09.17~ | 2500 | A25-AFXS | AXVH71L | RN2068V | PN1857 | RN1445 | PN1854 | |
| 06.17~ | 2500 | A25-AFXS | AXVH71R | RN2068V | PN1857 | RN1445 | PN1854 | |
| 12.17~ | 3500 | 2GR-FKS | GSV70L | RN1931VRN2068V | PN1857PN1845 | RN1445 | PN1854 |
| 07.20~ | 1800 | 2ZFR-FE | ZSG10 | RN2068V | PN1857 | RN1445 | PN1522PN1854 | |
| 07.20~ | 1800 | 2ZR-FXE | ZVG10 | RN2068V | PN1857 | PN1522 | ||
| 08.21~ | 1800 | 2ZR-FXE | ZVG11 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 07.20~ | 1800 | 2ZR-FXE | ZVG11LVN | RN2068V | PN1857 | PN1522 | ||
| 08.21~ | 1800 | 2ZR-FXE | ZVG15 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 03.21~ | 2000 | M20A-FKS | MXGA10 | RN2068V | PN1857 | PN1522 | FN0621 | |
| 03.21~ | 2000 | M20A-FKS | MXGA15L | RN2068V | PN1857 | RN1445 | PN1854 | FN0621 |
| 06.18~ | 2000 | 8AR-FTS | ARS220 | RN2068V | PN1857 | PN1868 | ||
| 06.18~ | 2500 | A25A-FXS | AZSH20 | RN2068V | PN1857 | PN1868 | ||
| 06.18~ | 2500 | A25A-FXS | AZSH21 | RN2068V | PN1857 | PN1868 |
| 06.20~ | 2000 | M20A-FKS | MXUA80 | RN2068V | PN1857 | RN1445 | PN1854 | FN0567 |
| 06.20~ | 2000 | M20A-FKS | MXUA85 | RN2068V | PN1857 | RN1445 | PN1854 | FN0567 |
| 06.20~ | 2500 | A25AFXS | AXUH80 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 10.20~ | 2500 | A25AFXS | AXUH80R | RN2068V | PN1857 | RN1445 | PN1854 | |
| 06.20~ | 2500 | A25AFXS | AXUH85 | RN2068V | PN1857 | RN1445 | PN1854 |
| 01.22~ | 1800 | 2ZR-FXE | ZWR90 | RN2068V | PN1857 | PN1868 | ||
| 01.22~ | 1800 | 2ZR-FXE | ZWR92 | RN2068V | PN1857 | PN1868 | ||
| 01.22~ | 1800 | 2ZR-FXE | ZWR95 | RN2068V | PN1857 | PN1868 | ||
| 01.22~ | 2000 | M20A-FKS | MZRA90 | RN2068V | PN1857 | PN1868 | ||
| 01.22~ | 2000 | M20A-FKS | MZRA92 | RN2068V | PN1857 | PN1868 | ||
| 01.22~ | 2000 | M20A-FKS | MZRA95 | RN2068V | PN1857 | PN1868 | ||
| 01.22~ | 2000 | M20A-FKS | MZRA97 | RN2068V | PN1857 | PN1868 |
| 04.19~10.23 | 2000 | M20A-FKS | MXAA52 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 11.18~ | 2000 | M20A-FKS | MXAA52L | RN2068VRN1931V | PN1857PN1845 | RN1445 | PN1868PN1854 | |
| 11.18~ | 2000 | M20A-FKS | MXAA52R | RN1931VRN2068V | PN1845PN1857 | RN2253VRN1445 | PN1868PN1854 | |
| 11.18~ | 2000 | M20A-FKS | MXAA54 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 11.18~ | 2000 | M20A-FKS | MXAA54L | RN1931VRN2068V | PN1857PN1845 | RN1445RN2253V | PN1854PN1868 | |
| 12.18~ | 2500 | A25AFKS | AXAA52L | RN2068V | PN1845PN1857 | RN2253VRN1445 | PN1854PN1868 | |
| 11.18~ | 2500 | A25AFKS | AXAA54L | RN2068V | PN1845PN1857 | RN2253VRN1445 | PN1854PN1868 | |
| 11.18~ | 2500 | A25AFXS | AXAH52L | RN2068VRN2417V | PN1845PN1857 | RN1445RN2253V | PN1868PN1854 | |
| 11.18~ | 2500 | A25AFXS | AXAH52R | RN2068V | PN1845PN1857 | RN1445 | PN1868PN1854 | |
| 05.19~ | 2500 | A25AFXS | AXAH54 | RN2068V | PN1857 | RN1445 | PN1854 | |
| 11.18~ | 2500 | A25AFXS | AXAH54R | RN2068V | PN1857 | RN1445 | PN1854 |
