NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2570

ROTOR DISC » RN2570

Specification

Type

Solid

Outter Ø

281

Num. of holes

5

Disc Thickness (Max)

10

Disc Thickness (Min)

8.5

Height

53.1

Centering Diameter

62

Pitch Circle Ø

114.3

Front/Rear

Rear

Structure Material

G3000

Hole Ø:

14.6

Drum Ø:

173

Cross Reference

TOYOTA

42431-06220

TOYOTA

42431-0A040

TOYOTA

42431-33160

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Camry

08.17~

2500

A25A-FKS

AXVA70L

RN2068V

PN1857

RN2570 RN1445

PN1522 PN1854

FN0621

TOYOTA » Corolla Cross

07.20~	1800	2ZFR-FE	ZSG10	RN2068V	PN1857	RN2570 RN1445	PN1522 PN1854
07.20~	1800	2ZFR-FE	ZSG10R	RN2068V	PN1857	RN1445 RN2570	PN1854 PN1522	FN0621
07.20~	1800	2ZR-FXE	ZVG10R	RN2068V	PN1857	RN2570	PN1522	FN0621
07.20~	1800	2ZR-FXE	ZVG11LVN	RN2068V	PN1857	RN2570	PN1522
03.21~	2000	M20A-FKS	MXGA10	RN2068V	PN1857	RN2570	PN1522	FN0621
