ROTOR DISC » RN2047V

RN2047V

Specification

Type
Vented
Outter Ø
281.3
Num. of holes
6
Hole Ø:
M12*1.25
Disc Thickness (Max)
26
Height
77
Centering Diameter
96
Pitch Circle Ø
130
Structure Material
G3000
Disc Thickness (Min)
24.6

Cross Reference

ISUZU
8-97126-048-0
ISUZU
8-97126-048-1
ISUZU
8-97126-048-2
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ISUZU   »   ELF

06.04~11.06 3100 4JG2 NHR69 RN2047V FN4465 FN4404

ISUZU   »   ELF150

07.93~04.97 3100 4JG2 NHR69C DN1435RN2047V FN4460 FN4428 FN4404
