DRUM BRAKE » DN1435

DN1435

Specification

Outter Ø
309
Num. of holes
6
Hole Ø
14.5
Centering Diameter
96.5
Height
109
Pitch Circle Ø
139.7
Drum Ø
279.4
Structure Material
G3000

Cross Reference

ISUZU
8-97034-798-0
ISUZU
8-97034-798-1
ISUZU
8-97034-798-2
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ISUZU   »   ELF

11.02~ 2800 4JB1 NHR55 RHD DN1435 FN4460 FN4428 FN4404
01.03~ 3100 4JG2 NHR69E DN1435 FN4460 FN4428 FN4404

ISUZU   »   ELF150

07.93~04.97 3100 4JG2 NHR69C DN1435RN2047V FN4460 FN4428 FN4404

ISUZU   »   Truck

11.02~ 2800 4JB1 NHR55E DN1435 FN4460 FN4428 FN4404
