ROTOR DISC » RN2045V

RN2045V

Specification

Type
Vented
Outter Ø
265
Num. of holes
6
Disc Thickness (Max)
35
Height
80
Centering Diameter
104
Pitch Circle Ø
142
Hole Ø:
M14*1.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

ISUZU
8-97031-007-0
ISUZU
8-97031-007-1
NISSAN
40206-89TA3
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ISUZU   »   ELF

06.93~02.07 3100 4JG2 NHS69 JPN RN2045V PN4384 FN4465FN4460FN4428 FN4443
01.94~06.02 3100 4JG2 WKR69 RN2045V PN4384 FN4428 FN4404
05.93~05.03 4300 4HF1 NKR RN2045V PN4384 DN1427 FN4461BL1055 FN4443
12.99~06.02 5000 4HJ1 NKR72 RN2045V BL1054FN4459PN4489PN4384PN4464 BL1055FN4451 FN4443
